ae-4020 - 2 Pages

Versatile Urine Analysis System

AUTION ELEVEN™

AE-4020

ARKRAY - Dedicated to Urine Analysis

ARKRAY, Inc. manufactured world's first urine analysis system in

1972. Since then, our award-winning R&D has continued to

deliver state-of-the-art reliable systems to help the laboratory

specialist in every possible situation.

Aution 11 - No More Compromises

Getting new systems for your laboratory is a difficult and time

consuming process. You are faced with many opinions and

different needs. This forces you to make choices and to

compromise.

With ARKRAYs latest urinalysis platform, the Aution 11, you can

forget about compromise. Don't choose, just get it all. The new

Aution 11 is so flexible and versatile, that it will meet your

requirements, no matter what your laboratory circumstances are.

This instrument was designed to function anywhere.

Specifications

Sample

Urine - applied to urine dipstick

Test Items

Compatible with Aution Sticks*

Measurement Principle

Dual wavelength reflectance method

Wavelengths

LED: 430, 565, 635 & 760 nm

Speed

up to 514 tests/hour

Reaction Interval

60 seconds

Data Memory

520 tests

Dimensions & Weight

W 210 x D 328 x H 164 mm, 3.6 kg

Built-in Printer

Thermal, 58 mm width

Display

Customized LCD (iconized)

External Output

RS-232C, Ethernet

Power Supply AC 100 - 240 V adaptor, 45 VA

Design and specifications may be subject to change without notice

Whether you are a high throughput lab, or run only several

routine samples per day, the Aution 11 will do the job for you.

AE-4020's speed, accuracy and reliability suit the central

laboratory; the compact size and minimal weight, allow you to

take it to the point of care.

Easy-to-use, Flexible, Versatile

The Aution 11 was built to make your daily routine easier and more

comfortable. Simply place the first dipstick and the process starts

automatically. The capacity is up to 514 test s/hour and 520 tests can

be stored in memory for database use and analysis. Other

convincing features are:

COLORLESS

»M£AS Mo. 0002

2CW-NJ-26 17:01 lOPfl 26" C

111111111r.1 nt

Color tone detection, automatic

temperature compensation etc. are all shown

on the detailed printout.

For both left- and right-handed use - optimize workflow

No screws to open - easy maintenance within minutes

Detailed printout - results immediately available

RS-232C PC output - advanced automation

Automatic feeder & timer - avoid errors

Urine sticks can be placed from both

the left-handed and right-handed side.

True Accuracy, for the True Professional

The laboratory professional needs reliable results. ARKRAYs urinalysis systems

give you unmatched ease and automation, and accuracy to rely on. The core of all

ARKRAY systems is our product line of high quality urine dipsticks, Aution

Sticks*. These sticks guarantee precision, sample after sample.

With the unmatched ability to manufacture both instruments and reagents,

ARKRAY is a unique partner in the urine analysis laboratory.

*The Aution 11 is set standard to work with AUTIONSticks- 10EA. Ask your distributor

for detailed specifications and which products are available in your country.




H-1HQ AvJuL | J-CO mnOH.]



■ input (OlliiAl

i i.itnl ^jd (015-1 a □ 1



a 0 mjML <0 5

O 4 Ji 0 TWV*. (0 1 100 umoH.)



.■ .-^v JI. i !■■ [»n*n i

3-0 irti-A (35-190 pA|



1 a Mill rwig«

ct pHJ-O

pHS-D



■ <™ Ifl 1 One ITJ

mm m n ncfi

■ WQ.1QW



Eiythmnrti waul la Ery*]jt.

I hMiM^'iim 0 113-1 0 mrtftsi-

11 ■•monioon 0 7M0 i^on.)



«4 □ ft mi™*!.1




U!H^I! Id'-nfl |1MV|iM

Nnr*» p »F»S in.

MW» 0.06-0 ft n■okll

initnn OJB-O man!)

..... ,-. .

Mud 7ft 1 n-jl^J



a rKray, i nc.

Travi

KYOTO MIYUKI Bldg. 1 OF, 689 Takanna-cho, ^siXj

Nakagyo-ku.Kyoto 604-8153, JAPAN

TEL +81-75-662-8967 FAX +81-75-662-8973

URL http://www.arkray.co.jp/english

B110629-01
