ARES-1204G - Datasheet

ARES-1204G - Datasheet

Product catalog summary

Overview: The ARES-1 Series Industrial VESA mounting kits are designed for various display sizes and weights, offering flexibility in mounting patterns and support for different panel sizes. The series includes models ARES-12290, ARES-12390, ARES-12240, ARES-1204G, and ARES-12250, each with specific features and specifications.

Specifications:

ARES-12290 & ARES-12390: Support panel sizes from 15" to 52" with a maximum weight of 60 kg. They feature mounting patterns of 200x200, 200x100, and 100x100 mm. The ARES-12390 includes a hinge module with a tilt range of 0 to -15°.
ARES-12240 & ARES-1204G: Designed for smaller panels ranging from 7" to 32" with a weight capacity of 2 to 10 kg. They offer mounting patterns of 100x100 and 75x75 mm, with swivel, tilt, and pivot capabilities.
ARES-12250: Supports panel sizes from 7" to 32" with a maximum weight of 25 kg, featuring a mounting pattern of 100x100 and 75x75 mm.

Materials and Construction: All models are constructed from steel, with some incorporating aluminum alloy and plastic components. They are equipped with safety locks, except for the ARES-12250, which does not include a safety lock.

Ordering Information: Each model has a specific part number for ordering, such as ARES-12390-F202000 for the ARES-12390 model, which supports 22" to 52" displays and is tiltable.

Compatibility: The document includes a compatibility table listing various system models and their compatibility with the ARES series mounts, detailing panel sizes, weights, and VESA patterns supported.

Additional Features: Some models offer user torque adjustment and cable management options, enhancing usability and installation flexibility.

Note: All product specifications are subject to change without notice, and the document was last updated on July 19, 2024.

Catalog excerpts

Industrial VESA mounting kit Color Options: Color Options: Screw Type Screw Type Mounting Pattern Hinge Module Panel Size Support Mounting Pattern Display Support Panel Size Support Display Support Min. Distance To The Wall Safety Lock Ordering Information Safety Lock Anti-Theft Lock Ordering Information All product specifications are subject to change without notice

Open the catalog to page 1

Industrial VESA mounting kit Color Options: Swivel Tilt Pivot User Torque Adjust Mounting Pattern Panel Size Support Support Weight (Range) Display Support Min. Distance To The Wall Color Options: Net Weight Dimension (W x H x D) Screw Type Material Hinge Module Patented VESA Bracket Net Weight Dimension (W x H x D) Screw Type Material Swivel Tilt Pivot User Torque Adjust Mounting Pattern Panel Size Support Support Weight (Range) Hinge Module Display Support Min. Distance To The Wall Ordering Information Ordering Information Product PN Wall Mount, support 15~32", 2~10 kg, 75x75/100x100mm Wall...

Open the catalog to page 2

Industrial VESA mounting kit Color Options: Specifications Net Weight Dimension (W x H x D) Screw Type Material Display Support Min. Distance To The Wall Safety Lock Mounting Pattern Panel Size Support Support Weight (Max.) Ordering Information Product PN Wall Mount, support 15" ~ 32", max.support 25kg, 75 x 75 /100 x 100mm

Open the catalog to page 3

Compatible Table Model Name Part Number Get the latest version HERE Max. support weight Max. support panel size System Model Panel size (inch)

Open the catalog to page 4

Compatible Table Model Name Part Number Get the latest version HERE Max. support weight Max. support panel size System Model Panel size (inch)

Open the catalog to page 5
