AvaSpec-HERO SensLine


Catalog excerpts

AvaSpec-HERO SensLine - 1

AvaSpec-HERO SensLine The AvaSpec-Hero is the top of the line spectrometer! Based on High Sensitivity Compact optical bench (f=100mm; NA=0.13) and a 1024x58 backthinned CCD detector, it offers the best of both worlds: Sensitivity and Resolution! The instrument is equipped with a TE Cooling enabling long integration times in low light applications. In conjunction with our AS7010 electronics, including a high end AD convertor, noise is kept to a minimum, which offers you an excellent Signal to Noise and Dynamic Range performance. A selection of gratings and slits offers you the flexibility of configuring the instrument for a wide range of applications in the 200-1160nm range. From low light fluorescence applications to demanding Raman applications, the AvaSpec-Hero is your ideal companion. With the high speed USB3.0 and Gigabit Ethernet communication interface, the connection to your computer is fast and simple. Of course the Digital IO ports enabling external triggering, control of shutters, and pulsed light sources from the Avantes line of instruments are available as well. The Avaspec-HERO is standard equipped for use with replaceable slits, offering optimal flexibility for a variety of applications. The combination of all the above makes the AvaSpec-Hero your ideal companion for all your spectroscopic measurements. Optical Bench Wavelength range Resolution Stray-light Sensitivity Detector Temperature cooled CCD Signal/Noise Dynamic Range AD converter Integration time Interface Digital IO Sample speed with on-board averaging Data transfer speed Power supply Dimensions, weight Technical Data: AvaSpec-HSC1024x58TEC-EVO HSC Symmetrical Czerny-Turner, 100 mm focal length, NA: 0.13 200-1160 nm 0.2-7 nm, depending on configuration (see table) 0.5%, depending on the grating 445,000 counts/pW per ms integration time CCD array image sensor with one stage TE Cooled, 1024 pixels Max. AT = 30 °C versus ambient 1200:1 40.000 16-bit, 250 kHz 5.2 ms- 60 sec USB 3.0 high-speed, 5 Gbps Gigabit Ethernet 1 Gbps HD-26 connector, 2 Analog in, 2 Analog out, 3 Digital bidirectional, trigger, sync., strobe, laser. The new AvaSpec-HERO is the answer for those who are in need of high resolution and high sensitivity! enlightening spectroscopy

Open the catalog to page 1
AvaSpec-HERO SensLine - 2

Order code UV/VIS/NIR UV/VIS/NIR VIS/NIR UV/VIS VIS/NIR VIS/NIR UV/VIS VIS/NIR UV/VIS * depends on the starting wavelength of the grating; the higher the wavelength, the bigger the dispersion and the smaller the range to select. Resolution table (FWHM in nm) for AvaSpec-HSC1024x58TEC-EVO Grating (lines/mm) 300 400 600 830 1200 2400 * Above values are average values. Due to optical properties resolution will be better in the lower wavelengths than in the higher wavelength range. SLIT-XX-RS SLIT-XX-RS-FCPC SLITKIT-SMA SLITKIT-FCPC OSF-YYY-3 OSC-HSC300 OSC-HSC600 AvaSpec-HERO; High sensitivity...

Open the catalog to page 2
