Best conditions for your success

Safety drying chambers A BINDER heating oven with a silicone- and dust-free inner chamber and a symmetrical air flow provides the perfect environment for standard-compliant drying of paints and coating materials containing solvents. The FDL Series guarantees short drying time with high temperature accuracy and defined ventilation. Every BINDER heating oven thus represents the basis for the highest-quality results and reproducible tests in the fields of chemistry and surface technology. The replaceable fresh air cartridges are easy to change and ensure constant fresh air quality. The safety concept...

Product selection | Safety drying chambers General data Temperature range 10 °C above ambient temperature to [°C] 300 Forced convection • Controller and timer functions Ramp function • Temperature dependent delayed OFF • Programming option • Weekly program function • Real-time clock • Class 2 independent adjustable temperature safety device • Temperature alarm, visual • •Standard equipment

Safety drying chambers | Advantages at a glance FULFILLS THE SAFETY REQUIREMENTS OF EN 1539:2015 Series FDL Fresh-air monitoring with automatic deactivation of the heating and replaceable Class M6 filter cartridge fulfills the DIN EN 779:2012. PRECISE TEST CONDITIONS Series FDL BINDER APT.line™ preheating chamber technology provides symmetrical airflow and defined flow speeds. CONVENIENT WORK ENVIRONMENT Series FDL The interior concept includeds rack with tilt protection, no permanent fixtures and stainless steel interior.

Series FDL | Safety drying chambers MAIN FEATURES Replaceable filter cartridge, Class M6 Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm • Temperature range: room temperature plus 5 °C to 300 °C • APT.line™ preheating chamber technology • Controller with time-segment and real-time programming • Fresh-air monitoring with audible and visual alarm and automatic deactivation of heating Model Interior Online data sheets Find all details online go2binder.com/en-FDL

TECHNICAL DATA Description FDL 115 Measures - Outer dimensions Measures - Internal Dimensions Net weight of the unit (empty) [kg] 90 Performance Data Temperature Temperature range 10 °C above ambient temperature to [°C] 300 Recovery time after 30 seconds door open at 150 °C [min] 12 Electrical data Nominal power (Version 230 V) [kW] 2.9 Number of shelves (std./max.) 2/5 ORDERING INFORMATION [Art. No.] Further details: Go to www.binder-worid.com > Search > Enter Article Number Voltage Option model FDL 115 ► You will find a selction of options, accessories and services suitable for each product...

Excerpt from options and accessories | Safety drying chambers EXCERPT FROM OPTIONS AND ACCESSORIES For introducing external measuring instruments. Large selection of different diameters and Access port with silicone plug positions (left, right, or top) Series FDL Door gasket made of high-temperature-resistant silicone for operating temperatures > 200 °C. Door gasket Flap in the door, ideal for coil coating tests. Coil coating door flap You can access our installation, maintenance, calibration, validation, or warranty services by taking out a Maintenance Service Agreement or by simply getting...

BINDER products CO₂ incubators Incubators Cooling incubators Growth chambers Ultralow temperature freezers Drying and heating chambers Safety drying chambers Vacuum drying chambers Constant climate chambers Dynamic climate chambers Never miss a product novelty Subscribe and keep up to speed with the BINDER monthly newsletter. BINDER GmbH Tuttlingen, Germany BINDER Asia Pacific (Hong Kong) Ltd. Kowloon, Hong Kong, P.R. China Representative Office for CIS Moscow, Russia BINDER Environmental Testing Equipment (Shanghai) Co., Ltd. Shanghai, P.R.China 7002-0371 V10.2016 | Deviations from the figures,...
