Cartridge Solenoid Valve Type 6164

Product catalog summary

Overview: The Cartridge Solenoid Valve Type 6164 is designed for neutral gases, offering excellent reliability, optimal integration, low power consumption, and O2 compatibility. It is particularly suitable for applications requiring high durability and minimal maintenance.

Key Features:

Compact design with an 11 mm width per station.
Orifice sizes range from 0.5 mm (9 bar/130 psi) to 1.2 mm (1.5 bar/21.7 psi).
High durability with a lifespan of over 100 million cycles.
Low power consumption of 0.7W, with an optional ATEX Ex ia version.
Designed for optimal integration, especially in mobile devices.

Reliability: The valve's high lifespan allows for permanent integration without maintenance, ensuring reliability in production processes where uptime is critical.

Power Efficiency: With a power consumption of only 0.7W, the valve reduces overall device power usage, making it ideal for portable devices. It operates quietly, enhancing the user experience in sensitive environments.

Oxygen Compatibility: The valve is suitable for controlling oxygen gas, making it ideal for applications like mechanical ventilation and O2 concentrators, especially in sensitive settings such as neonatal care.

Integration: The valve's compact size (9mm diameter, 28mm height) allows for easy integration into plastic molded parts and compact devices, supporting a plug-and-play installation approach.

Technical Specifications:

Orifice and pressure range: DN 0.5 mm (Vac-9bar/130psi) to DN 1.2 mm (Vac-1.5bar/21.7psi).
Permissible leakage: VAC - 10 bar/145 psi.
Body material: PEEK; Seal material: FKM.
Medium and ambient temperature: -10 to +55 °C.
Electrical connection options: Plug/Solder, Flying leads on request.
Operation voltage: 12 and 24 V DC.
Power consumption: 0.7W (DN 0.5), 2.8W (DN 1.2).
Duty cycle: 100% continuous rating.
Response times: <10ms for both opening and closing.
Switching frequency: 16Hz; Switching noise: 42 dB.

Approvals and Conformity: The valve is prepared for various certifications, including ATEX Ex ia, IEC Ex, FM Class I Div II, UL class 2, and oxygen compatibility.

Catalog excerpts

Cartridge Solenoid Valve Type 6164 for neutral gases • Excellent Reliability • Optimal Integration • Low Power Consumption • O2 Compatibility

Open the catalog to page 1

Your advantages Superior ratio of size to fluidic performance The cartridge valve, Type 6164, simplifies pneumatic piloting controls through optimal integration in block solutions and plastic injection components. Due to its uncompromising reliability, above-average service life and efficient performance, this valve is setting new standards. Install and forget - this is the best way to describe the new standard cartridge valve, a 3/2-way valve with guaranteed reliability and a long life cycle, due to the use of high-quality materials. Reliability Every team is only as strong as its smallest player The...

Open the catalog to page 2
