Product Overview

The EFLH100 is an LED headlight designed for automotive applications, offering enhanced illumination performance and energy efficiency compared to traditional halogen or HID headlights.

Specifications

• Light Source: High-intensity LED modules
• Power Consumption: Optimized for low energy use while maintaining brightness
• Color Temperature: Typically around 6000K for clear white light
• Luminous Flux: High lumen output ensuring improved visibility
• Operating Voltage: Compatible with standard automotive electrical systems (12V/24V)
• Durability: Designed to withstand vibrations, temperature variations, and moisture

Installation Procedures

The headlight unit is designed for straightforward installation with standard connectors. Proper alignment is critical to ensure optimal beam pattern and avoid glare. Installation steps include:

1. Disconnect vehicle battery before installation.
2. Remove existing headlight assembly if applicable.
3. Connect the EFLH100 LED headlight to the vehicle’s wiring harness.
4. Secure the headlight assembly firmly in place.
5. Adjust beam alignment according to manufacturer guidelines.
6. Reconnect battery and test functionality.

Standards and Compliance

The EFLH100 complies with relevant automotive lighting standards, including:

• ECE Regulation 112 for LED headlights
• SAE J575 for photometric performance
• IP67 rating for water and dust resistance

Recommendations and Best Practices

• Ensure compatibility with vehicle electrical system before installation.
• Use professional alignment tools to adjust beam pattern.
• Regularly inspect headlight for damage or dirt to maintain performance.
• Avoid direct exposure of LED modules to water jets during cleaning.

Key Benefits

• Improved night-time visibility and safety.
• Lower power consumption extends vehicle battery life.
• Longer lifespan reduces maintenance frequency.
• Robust design suitable for various environmental conditions.
