DEKO 190 Ward Washer Disinfector Preventing infections since 1976.

Intended use The DEKO 190 Ward Washer Disinfector empties, cleans and thermally disinfects by steam a variety of reusable ward utensils, such as; Portable sanitary pans Urine bottles and kidney dishes Hospital bowls (patient wash bowls) Raised toilet seats and toilet brushes / holders Suction bottles, measuring jugs and various hollowware Products alike the above and used for similar purposes within patient care

Fresh-water recirculation principle simiLar to instrument washer-disinfectors provides superior cLeaning and disinfection results. Thanks to high water pressure combined with minimum usage of water and energy, an outstanding mechanicaL washing efficiency is reached on economic consumption vaLues. ThermaL disinfection is executed according to EN ISO 15883 A0=600 requirement and carried out by steam, integraLLy generated in an unpressurized steam generator. ALL internaL surfaces are washed and in addition to the utensiLs being processed, the water tank, piping, outLet and chamber are disinfected...

Features and functionalities – benefits for the user Large Capacity, extended versatility Large wash chamber and capacity for automatic emptying and processing of 2 bedpans with lids and 4 urine bottles simultaneously. The machine is equipped with an integrated drop-down shelf and it can also accommodate specialized inserts and washing accessories to process a large variety of utensils used at wards. See the brochure for further information on available washing accessories. Advanced State-of-the-art control Control by a Programmable Logic Controller (PLC) with the most advanced operating system...

Network connectivity (Ethernet) (optional feature) Network connectivity feature allows: • Remote monitoring of the machine over network • Logging process events over network to email client • Sending process data printouts to local and network printer • Storing process data to external fileserver (FTP over Ethernet) • Available for DEKO 190 X2. See “DEKO WD networking, System description” for more information. Detergent dosing • Suction tube: The length of the suction tube is adjustable to ensure fit for all types of detergent containers. Remote access (optional feature) Capability for remote...

Programs are easily adaptable to suit special washing and disinfection requirements.

Material Stainless EN 1.4301 steel User interface / Display Door functioning Automatic Non-Touch, optical sensor O Washing mechanics 3 rotating + 7 fixed wash jets X Water recirculation pump, power kW / output l /min 1.6 / 600 Usable chamber volume, l Wash chamber dimensions, mm (gross) Floor loading, kN/cm2 Adjustable feet for levelling ±10 mm Utility connections and consumption Back syphon protection * Cold water (max 15°C) inlet hose, G1/2” female thread, length 2 m Warm water (max 65°C) inlet hose, G1/2” female thread, length 2 m Min - max water pressure, bar Water volume per cycle phase,...

Load temperature protection and over temperature cut-outs Pressure control for foam and washing water Cycle complete indication with mutable buzzer Boss entry port for test temperature sensor leads Independent tamper-proof process verification Independent tamper-proof process recorder Panel printer Network connectivity (Ethernet) Remote access Emergency stop switch O Regulations and standards compliance Medical Device Regulation, EU MDR 2017/745 X RoHs 2011/65/EU, The Restriction of Hazardous Substances Directive X X = Standard O = Optional. - = Not avaiLabLe / not appLicabLe * = RegionaL options...

1. See available voLtage rating variants on page 9. 2. CoLd water, fLexibLe inLet hose with G^” femaLe thread, L = 2 3. Warm water, fLexibLe inLet hose with G^” femaLe thread, L = 2 m 4. Waste outLet fLoor instaLLation 0110 mm (dimensions for center of the outLet) 5. Steam (steam heated modeLs onLy), fLexibLe steeL armored inLet hose with R^” maLe thread, L=1,2m 6. Condense (steam heated modeLs onLy), fLexibLe steeL armored inLet hose with R^” maLe thread, L=1,2 m 7. Waste outLet waLL instaLLation at 220 ±10 mm 0110 mm (dimensions for center of the outLet, option to fLoor instaLLation) 8. Waste...

Main display and operation keys

DEKO MedTech Oy | Vartiokuja 1 | FI-76850 Naarajärvi | Finland www.dekomedtech.com Preventing infections since 1976.
