Product catalog summary
Key Features & Benefits
A pair of full-spectrum, linear, and bidirectional LED lamps, each measuring 224 cm, offers flexibility in installation. The bidirectional lighting ensures uniform illumination, optimizing conditions for precision dental work and reducing eyestrain and fatigue. Key features include:
  • Direct/Indirect lighting for uniform distribution.
  • High Colour Rendering Index (CRI >90) for accurate shade matching.
  • Flicker-free to prevent fatigue.
  • Low glare for comfort.
  • High output of 1500–2000 lux at the oral cavity.
Installation
DentLed provides optimal lighting solutions for dental surgeries, practices, and labs, with installations in over 1300 treatment rooms. They collaborate with accredited technicians for installation and maintenance, offering flexibility for preferred installers.
Technical Specifications
  • Output: 2 x 15,000 lm
  • CRI: 90+
  • CCT: 5000 K
  • Efficacy: 100 lm/W
  • Power Consumption: 2 x 150 W
  • Dimensions: 2245 x 51 x 81 mm
  • Weight: 2 x 7.4 kg
  • Color: White, black, or custom
  • Flicker Free: Yes
  • Lifetime: 50,000 hrs/20 yrs
  • Power Cord Length: 3 m
  • Max Suspension: 2 m
  • Direct/Indirect: 70% / 30%
  • Dimmable: Option/dali included
  • Suspension Points: Fixed
  • UGR: <19
Contact Information
For further details, contact DentLed at +31 303 100 500 or [email protected]. Address: Mariaplaats 3, 3511LH Utrecht.
See more

Catalog excerpts

DentLed_PHL22_EN_Specifications-1

PHL22 224cm dual-linear dental lighting Reduce fatigue & Improve ergonomics A pair of full-spectrum, linear, and bidirectional LED lamps, each measuring 224 cm in length. two independent lamps offer flexibility in installation as required. Bidirectional lighting guarantees uniform illumination across the treatment room. This ensures clear and comfortable lighting, optimizing conditions for precision dental work. Incorrect lighting in dental treatment rooms leads to eyestrain and fatigue. DentLed's full-spectrum lighting was developed specifically as the optimal work light for dental treatment rooms. Key features & benefits Direct/Indirect lighting: Uniform light distribution across the treatment room. High Colour rendering for accurate shade matching (CRI >90). Flicker free: no fatigue inducing flicker. Low glare: Light is not harsh & unpleasant on they eyes. High output: 1500–2000 lux at the oral cavity.

 Open the catalog to page 1
DentLed_PHL22_EN_Specifications-2

Colour rendering Output (lumen) Power Consumption White, black or custom Flicker Free Power Cord Length Option/dali incl Suspension Points Light intensity distribution Accurate colour rendering for correct shade matching. Installation DentLed collaborates with accredited technicians to install and maintain full spectrum lighting solutions in your dental practice. For further details, please get in touch with us. If you have a preferred installer, installation can be arranged through them as well. 2000 lux - desired ambient light intensity at work area This diagram illustrates the optimal light...

 Open the catalog to page 2
