mobile c-arms

MOBILE C-ARMS Mobile imaging systems Following applications: general surgery, orthopedic, pediatric, abdominal and neurosurgery, urology in combination with lithotripter, traumatology, digital subtraction angiography (DSA) High frequency pulsed generator associated with :  stationary anode (EVO+) : Microprocessor controlled high frequency generator 3,5 kW  rotating anode (EVO R+) : Microprocessor controlled high frequency generator 5 kW Enables all modes: continuous fluoroscopy, pulsed fluoroscopy and digital radiography High resolution image intensifier: 9” (23 cm) triple field. Cassette holder...

MOBILE C-ARMS Main options:  Dose Area Product Meter (DAP) kit including chamber, electronics and display unit  Virtual collimation  Zero dose digital rotation  Parallel Shu

MOBILE C-ARMS Mechanical Features

MOBILE C-ARMS Mechanical Features SID 980 mm rotating anode 988 mm fixed anode

MOBILE C-ARMS Mechanical Features Free space 720 mm Arm depth 690 mm

MOBILE C-ARMS EVO+/EVO R+ Range EYES Compact Performance

EVO+ / EVO R+ With memory EYES UNIT CONFIGURATION Monobloc : fixed or rotating anode I.I. Tube : 9” triple field CCD camera: 1 x 1 k Memory: Eyes Monitor: 24” color (on the trolley) 24” touch screen color (on the C-arm for compact version) Standard equipment: CD/DVD reader (not for compact) USB port (bmp export DICOM opt.) Ethernet port (DICOM) C-arm lateral handlers Cassette holder: 24 x 30 Options: printer Sony : UP971 or UP991 All DICOM modalities (NO DSA) DICOM WI-FI USB DAP and DAP printer Laser (on I.I. side) Sterile drapes

The unit configured with EYES allows:  Electronic image rotation at 1°, recursive filters.  Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %)  Pulsed Fluoroscopy Rates: 12 p/s, 6 p/s, 3 p/s, 1 p/s.  Dedicated APR curve to allow Continuous Fluoro up to 15 mA for sturdy patient (only for rotating anode).  Patient Database, Patient Data end exam type.  Storage capacity max. 55.000 images 1k x 1k.  Virtual collimators on LIH.  All DICOM...

Monoblock : fixed or rotating anode I.I. Tube : 9" triple field CCD: camera: 1 x 1 k Memory: RTP1000 Monitor : 19" B/W CD/DVD reader USB port (bmp export DICOM opt.) Remote infrared controller Ethernet port (DICOM) Cassette holder: 24 x 30 C-arm lateral handlers Options: printer Sony : UP971 or UP991 All DICOM modalities DICOM wireless module DAP and DAP printer Laser (on I.I. side)

The unit configured with RTP 1000 allows:  DSA with automatic and manual mask, road mapping, cineloop, digital image rotation with angle displayed, recursive filters.  Image post processing elaboration (H/V image flip; customizable post processing LUT; b/w inversion; electronic shutters; spatial filters; digital magnification; image annotations and measures like stenosis %)  Pulsed Fluoroscopy Rates: 2 i/s, 1 i/s, 1 i/3s.  Dedicated APR curve to allows Continuous Fluoro up to 15 mA for sturdy patient (rotating anode only).  Auto image storing every: 1/3/6/12/25 fps.  Patient Database, Patient...

MOBILE C-ARMS Intended use • Traumatology • Orthopedics • Vertebroplasty • Pacemaker implantation • Peripheral Angiography • Digestive system • Generic Surgery • Biliary drainage and stenting • Image guided biopsy

Main Applications and suggested Memories  Are you going to do any exam with Contrast Media? (HCF/DSA with acquisition required)  Prevalent Body Region and duration of the exam? (Fixed/Rotating Anode and Memory)  Resolution expected by the images? (CCD, Monitor, Memory)  Only as an example, here below are listed some «suggested applications» accordingly to the Memory type: -EYES: Orthopaedics, Pacemaker, Litotripsy. -RTP_1000 : pacemaker, endoscopy, biopsy , endovascular surgery, Peripheral angio

ADDRESS > 9 Avenue du Canal Philippe LAMOUR - 30660 Gallargues-le-Montueux - FRANCE PHONE > +33 4 66 29 09 07 – www.dms-imaging.com
