Isokinetics - Prima Line

Product catalog summary

Overview
The document describes the Linea Prima isokinetic devices designed for rehabilitation and athletic training, focusing on large joints such as the knee, shoulder, and ankle. These devices provide constant speed exercises with accommodating resistance, allowing for maximal muscular contraction throughout the exercise.

Product Features

Prima Iso: A passive isokinetic dynamometer offering concentric and isometric modalities. It features a hydraulic brake, adjustable angular velocity, and real-time feedback on muscle forces and joint angles.
Prima Plus: An active and passive isokinetic dynamometer supporting concentric, eccentric, mixed, and isometric exercises. It also includes a hydraulic brake and provides real-time feedback.

Technical Specifications

Both devices have a size of 70x140x135h cm, with Prima Iso weighing 162 kg and Prima Plus 194 kg.
Electrical requirements include a power supply of 100-230 Vac, 50/60 Hz, with Prima Iso consuming 110 VA and Prima Plus 550 VA.
Installation conditions require a room temperature between 10°C and 40°C, relative humidity up to 75%, and atmospheric pressure between 700 and 1060 mbar.

Applications
The devices are suitable for muscle and joint traumatology, postoperative care, and athletic training. They allow for the assessment and recovery of joint strength and range, monitoring of dynamic muscle performance, and customization of workloads.

Certification and Compliance
Both Prima Iso and Prima Plus are compliant with the European Union Regulation 2017/745 and are classified as medical devices, with Prima Iso as Class I and Prima Plus as Class II b. The quality system is certified under ISO 13485.

Contact Information
Easytech s.r.l., Via della Fangosa, 32, 50032 Borgo San Lorenzo, Firenze, Italy. Email: [email protected], Website: easytechitalia.com, Phone: +39.055.8455216.

Catalog excerpts

Linea Prima

Open the catalog to page 1

Isokinetic - Linea Prima Prima Line Our product line, specifically developed for the assessment and recovery of large joints. The isokinetic exercise, performed at constant speed by accommodating resistance. For each large joint Prima allows: Thanks to our devices, the movement is executed at a constant speed in which the resistance adjusts to oppose the force exerted by the user. The result is a maximal muscular contraction continuing for the entire duration of the exercise and extending to all degrees of joints. Prima Iso and Prima Plus are designed for the training of the large joints: knee,...

Open the catalog to page 2

Isokinetic - Linea Prima Isokinetic - Linea Prima Prima Plus Passive isokinetic dynamometer. Concentric and isometric modalities. Active and passive isokinetic dynamometer. Concentric, eccentric, mixed and isometric modalities. Isokinetic dynamometer with hydraulic brake Assessment of the torque with 1.5 Nm resolution Contraction modes: isokinetic, isometric, isotonic and hydrodynamic Maximum concentric force 600 nm +/-5% Isokinetic concentric exerciseisometric mode Adjustable angular velocity range from 40°/sec to 400°/sec Isometric positioning by 15° intervals (30° for the shoulder) Isokinetic...

Open the catalog to page 3

Isokinetic - Linea Prima Technical features Operating configuration Installation requirements Isokinetic unit with seat Room temperature: [+10; +40] °C Relative humidity (without moisture): [0; +75] % Atmospheric pressure: [700; 1060] mbar Maximum patient weight: 135 kg Knee lever Ankle lever CKC lever Shoulder lever Lever cart Operating system Windows Graphic card 1024x768 - 24 bit Ram 4GB USB port Options Bipodalic lever Size and weight Prima Iso: Isokinetic unit 70x140x135h cm, 162 kg Prima Plus: Isokinetic unit 70x140x135h cm, 194 kg Levers trolley: 46x46x42h cm, 38 kg Min. required operating...

Open the catalog to page 4

Easytech s.r.l. [email protected] easytechitalia.com Via della Fangosa, 32 50032 Borgo San Lorenzo, Firenze T +39.055.8455216 CERTIFIED QUALITY SYSTEM ISO 13485 Rehabilitation Technology.
