Main Specifications
VIBROLITH Ortho is a pneumatic and electro-kinetic, unfocused extracorporeal shock wave therapy (ESWT) device. It operates on the principle of a bullet accelerated by compressed air impacting an applicator, which transmits energy to the treatment area. The device is designed for high-efficiency treatment of both soft and hard bone tissues.

Applications
Soft tissue applications include conditions like calcified tendonitis, epicondylitis, achillodynia, plantar fasciitis, and patellar tendinopathy. Hard tissue applications cover reactive periostosis, bone fractures, coxarthrosis, root arthrosis, Sudeck syndrome, pseudarthrosis, and osteoporosis.

Features
The device features an LCD display and is controlled via buttons or a touch screen in the "Touch" model. It is economical with low installation and maintenance costs and complies with European Safety Standards to prevent electrical hazards.

Technical Specifications

• Operating Pressure: 0-4 Bar, continuously adjustable
• Frequency: 1-24 Hz
• Pulse Mode: Single and Multiple (60–1440 Pulses/min)
• Energy: 0.16 mJ/mm²
• Power Supply: 220 V AC, 50 Hz (+/- 10%)
• Isolation: Internally transformer isolation
• Dimensions: Main Unit - 310x125x295 mm; Hand Piece - 185x20 mm
• Applicators: 6mm, 10mm, 15mm, 20mm
• Weight: 6.3 kg
• Electrical Safety: EN 60601-1, Class I, Type B; EN 93/42/EEC/MDD, Class IIb

Contact Information
ELMED Electronics & Medical Industry & Trade Inc. is headquartered in Ankara, Turkey, with an office in Orlando, Florida, USA. Contact details include phone numbers and email addresses for both locations.
