LF 2100

LF 2100
3Pages

Catalog excerpts

immmm rai UFM® • Structure : upright type, realized in sheet steel epoxy coated white colour both in- and outside or in stainless steel _ 18/10 AISI 304 both in- and outside. All the internal corners are rounded to make easy any cleaning operations and the internal bottom is tray type to contain spills • Insulation : high density (40 Kg/m3) foamed-in-place polyurethane, with a thickness of 75 mm. CFC-free • Feet : Nr 6 made in stainless steel 18/10 AISI 304, adjustable in height for levelling • Insulated doors : Nr 3, hinged, side-byside, made with the same material and insulation as the rest of the structure (sheet steel epoxy coated white colour or stainless steel 18/10 AISI 304 always both in- and outside). The doors are provided with a removable magnetic rubber gaskets in order to grant a perfect hermetic closing and the closing profiles are heated to avoid the gasket frosting. The handles are flush-fitting type so do not increase the size of the refrigerator. The doors are also fitted with a spring loaded automatic closing devices for openings inferior 90° and special door switches that stop the internal ventilation at the door opening (to limit the air cold loss) and light the internal lighting at every opening • Internal equipment : Nr 9 (3 for each door) storage open wire shelves realized in sheet steel with a strong plastic coating (rust-proof material). The shelves are mounted on special anti-tilt stainless steel slides that allows the shelf extraction and they can be easily removed and adjusted in height without the use of any tool. The special internal racking-system allows a great flexibility of the internal fitting with the possibility of interchange and combine both shelves and drawers (drawers optionally available) • Shelf dimensions (W x D cm) : 53 x 65 • Shelf loading capability (Kg) : 35 (with uniformly stored material) Internal lighting : Nr 3 bulbs, mounted in the bottom part of the control panel (1 above each door), with automatic activation both at every door opening and even through a touchpad on the control panel Control panel : located in the top part of the structure (above the door), it is microprocessor operating with 6 soft-touchpads and LED display, allowing the control of all the functions and working status of the freezer (including alarms). The main functions of the control panel are : • LED display, with bright indication, red colour, of the actual internal temperature and enlightened icons in green colour indicating the appliance working status (compressor functioning, defrosting, fan running, etc.) • Digital temperature adjusting and displaying with an accuracy of 0,1°C • Keyboard buttons with locking protection, manually activable, to avoid tampering from unauthorized persons • Visual and acoustic alarm signalling (with automatic resetting) for: - high and low temperature with limits programmable from the user - door ajar, delayed to allow the standard operations - power failure (at the return of the mains supply) - anti-freezing evaporator EVERmed Sri Via Galileo Galilei 2, 46020 Motteggiana (MN) - ITALY Tel.: +39 0376 550828 - Fax: +39 0376 550831 E-mail: evermed@evermed.it - Http: www.evermed.it

Open the catalog to page 1

immmm rai fIFM® - sensors failure • Muting facilities for the acoustic alarms with maintaining of the visual indication of the alarm condition • Alarms memory for the last 10 alarm conditions, with the possibility of checking from the display, the sort of alarm, when the alarm is started, when it is ended and which is the highest or lowest peak reached from the temperature (where applicable) • Ntc type sensors for a high accuracy of the temperature control • NO/NC contact to remote the alarm signals • Cooling unit : top mounted, with the condensing unit compounded by Nr 1 hermetic...

Open the catalog to page 2

immmm rai UFM® ACCESSORIES AVAILABLE Extra wire shelf Wire basket Plastic partitions for drawers Kit of castors Temperature chart recorder Internal electrical socket Extra stainless steel wire shelf Stainless steel drawer Front top for drawers Safety door lock with key Electronic temperature printer GSM/GPRS telephone dialer Different voltage Wooden crate packing Product certified as medical device in class IIa (Certificate N. 1448/MDD) * The declared performances are referred at +32°C ambient temperature, relative humidity of 70% and without any internal thermal mass (empty cabinet). *...

Open the catalog to page 3
