EWELLIX A Schaeffler Company Solutions for ophthalmic equipment

Ewellix is a global innovator and manuacturer of linear motion and actuation solutions. f Our state-of-the-art linear solutions are designed to increase machine performance, maximise uptime, reduce maintenance, improve safety and save energy. We engineer solutions for assembly automation, medical equipment, mobile machinery, distribution and a wide range of other industrial applications. Technology leadership Schaeffler Group – We pioneer motion We earned our reputation through decades of engineering excellence. Our journey began over 50 years ago as part of the SKF Group, a leading global technology...

Ophthalmic tables The Ewellix electro-mechanical lifting columns for ophthalmic equipment allow designers to provide their examination equipment with precise and ergonomic movements and maximum patient comfort. Ewellix solutions For example, series CPMA combines robust load-carrying capacity, silent lifting, and excellent design flexibility in a compact, two-section unit. A built-in universal power supply, cable-through for mains, switch and optional for LAN, and variable tube and motor placement capabilities enable several column configurations. Socket box accessories can be added to provide...

Ophthalmic chairs Today’s ophthalmic equipment manufacturers face a challenging mix of performance and cost pressures. As a result, demand is rising for ophthalmic chairs and instrument tables that offer more precise, ergonomic motion, greater load-carrying capacity, and increased functionality. Ewellix supports your product development with a complete platform that offers faster time to market. Our lifting columns combine smooth, silent lifting, short retracted height and a wide range of design flexibility. In addition, our linear guides provide additional freedom in positioning the patient...

All you need for ophthalmic instrument tables Lifting column – series CPMA Electrical connection to column (mains power, ground, switch, LAN) Electrical connection to column (mains power, ground, switch, LAN) 4 mm plate with 8 holes for screws to fasten column inner or outer tube to the base Mechanical fostening to column inner or outer tube plate by 4 x M6 screws IEC inlet socket for detachable mains powercord with strain relief Mounting plate with 4 holes to assemble table top 3 Sockets for instrument or equipment (max 8 A) RJ45 connector for foot switch LAN connection for instrument and desk...

Solutions for ophthalmic equipment Lifting columns Retracted length Stroke + 180 mm Stroke + 160 mm Stroke + 270 mm Stroke + 130 mm Control boxes Linear guides Output volatge (nominal) 24 VDC Total output current (max) 7A Operating device ports 1 Single fault safety ✓ Dynamic load rating up to 37,5 kN Material options Stainless steel Characteristics Easy integration Max. operating channels Operating power for power and feedback status RJ45 HD15 D-SUB/FCC RJ45 50 mA 50 mA 20 mA 50 mA single color single color 2 colors LED single color LED for LED for for power LED for power power and power status...

Supporting tool Digital Ewellix has developed a portfolio of tool to support customers in easy selection and calculation the right Ewellix product for their application. Actuators • Product selection • Performance calculator • Cost saving calculator Linear guides • Product selection • Product calculator • Cross reference Publications Supporting documents are available for downloading on ewellix.com in each product page under technical data section: • operating manual • mounting instruction Actuator range Linear bearings units and shafts Lifting column CPMA/CPMB Control units Operating switches...
