PAX- 10
1 / 4Pages

Catalog excerpts

PAX- 10 - 1

10-Watt Precision-Aligned Pulsed Xenon Light Source PAX Family of Precision-Aligned Xenon Light Sources Features and Benets • Precision alignment-arc position precisely located (+/- 0.05 mm, 0.002 inches) relative to datum feature on the mounting surface • Ease of installation and convenient “plug and play” eld replacement • 10 Watts average power • Long life: >1.0 x 109 ashes • Spectral range from 120 to 2000+ nm • Available in two arc orientations Overview The PAX-10™ by Excelitas is a Precision-Aligned Pulsed Xenon Light Sources offering a full 10 Watts of power. It's compact design integrates the ash lamp, trigger circuit, and power supply in an EMI-suppressant enclosure. The PAX-10 features a pre-aligned arc position precisely located relative to a datum feature on the mounting surface of the case. This pre-aligned arc position allows for “plug and play” eld replacement, eliminating alignment time and reducing OEMs’ costs and machine down time. • Integrated package—ash lamp, trigger circuit and power supply, all in a robust EMI suppressant enclosure • Flexible mounting • User selectable analog or digital intensity control • CE Marked and RoHS compliant Applications • Absorption analysis • Immunoassay modules The PAX-10 utilizes Excelitas’ reliable pulsed Xenon ashlamp technology, delivering high radiant intensity over a continuous spectrum from the ultraviolet to the infrared. It provides a long life rating of over a billion ashes and is available in two arc orientations with user-selectable analog or digital intensity control. The PAX family is the ideal pulsed Xenon light source for clinical diagnostics, invitro diagnostics, life sciences, drug discovery, proteomics, and analytical instrumentation applications. • UV/VIS/NIR applications • Spectroradiometry • Liquid chromatography • Colorimetry

Open the catalog to page 1
PAX- 10 - 2

Electrical Output Input Specifications Parameter Main Discharge Voltage Inrush Current Standard Discharge Capacitors +5 V, 20-50 mA peak input, 10-100 µs pulse width, leading edge trigger Vref (Vo/Vref = 210) Analog or digital control External switch selectable Internal/External Intensity Adjust External switch selectable Spectral Range Input Connector Life time Light Output NOTE 1: Optically Isolated: Internal series resistor = 150 Ω NOTE 2: Operating conditions: 0.33 µF discharge capacitor. 1000 VDC discharge voltage. 10 Hz flash rate. Part Number Configuration PAX-10AB-C* 0 - vertical...

Open the catalog to page 2
PAX- 10 - 3

Flash Pulse Waveform Time (minutes) 1, Precision mounting requires dowel pins 2. Mounting kit available as an accessory. 3. Alignment provided from pin center to theoretical intersection of electrode tip.

Open the catalog to page 3
PAX- 10 - 4

Mechanical Outline Mechanical Dimensions Ordering Information Excilitas has designed an easy to use Evaluation Kit for testing the PAX-10 in your application. To request additional information, receive a quote, or place an order for the PAX-10, please contact your Customer Support team or visit our website at www.excelitas.com. . All values are nominal; specications are subject to change without notice. PerkinElmer, Inc. Excelitas Technologies 35 Congress Street 35 Congress Street Suite 2021 Salem, Massachusetts 01970 USA Salem, MA 01970 Telephone: (+1) 978.745.3200 P: (+1) 978-745-3200...

Open the catalog to page 4
