Product technical data sheet Medical Device EMDN Z121701 General features Intended use Refrigerator intended to store blood, fluids or body tissues for transfusion, administration or introduction into the body. Temperature range Factory setpoint | Increment Ambient working class | Climatic class Nominal capacity Gross capacity | Net capacity Blood bags capacity (450 ml) External dimensions (WxDxH) Internal dimensions (WxDxH) Net weight without any internal fittings Package dimensions | Weight Wooden crate on pallet 84 x 85 x 220 cm | weight 202,4 kg Monocoque type body, made of plasticized, non-toxic white steel interior/exterior, coated with a special antibacterial-type film, or in inner 18/10 Aisi 304 stainless steel. Rounded corners and tray-type inner bottom. Insulation type High density (43 kg/m3) in-walls injected PUF, without any CFC, environmental-friendly, water-foam based. Insulation thickness No. 4 unidirectional rollers + No. 2 stabilizing feet No.1 door made of tempered and low emissivity glass, self-closing thanks to the spring hinge and 90°stop position. Electric-digital lock with password protection Digital lock, the door is opened by touching an icon on the display. The function may be password protected. Mechanical release key supplied for emergency opening. Full LED, all length of inner chamber, automatic switching on at door opening or from the display when the door is closed. Energy saving functions Night & Day special function and electronic, low consumption fan motors. Provided drawers: Disclaimer: Images are purely indicative. The features and the accessories of the products may differ according to model and application. Cardboard on pallet 76x81x220 cm | weight 190,4 kg No. 7 fully extractible drawers made of aluminium, with dividers (WxDxH): cm 15x50x7,5 (nr 3 compartments) Refrigeration system Refrigeration Professional, ventilated, forced, hermetic compressor type. Automatic, adaptive, including condensate water vaporization Headquarter: Via Panagulis, 48 - 42045 Luzzara (RE) Italy VAT No. IT00934960352 Phone +39 0522 976232 - Fax +39 0522 976028 www.fiocchetti.com - Email: [email protected] - Pec: fiocchetti@pe

Electronic controller Electronic controller TOUCH controller Electronic controller featuring a 7" full touchscreen display based on microprocessor architecture.0.1°C resolution, temperature readings easily visible from a distance, a real-time temperature graph, and all operational data accessible on the home page. Integrated in user's interface Security features Settable user password Visual and acoustic for temperature alarms failures such as: • Open door • High temperature Alarm system • Power failure • Clogged condenser • Any functional failure/faulty parts Visual, acoustic alarm and fully...

Accessories available on request GSM module Plug-in module to notify on mobile phones, via sms, overall monitoring, alarms and failures of the refrigerator Converter module type 4-20mA (this accessory excludes the installation of the GSM module) Wi-Fi module Plug-in module to connect to, monitor and manage the refrigerator wirelessly FIOCCHETTI COLD EYES cloud monitoring Annual monitoring service, Cloud based, featuring the notification of alarms and failures from pc thanks to a dedicated app, including SMS messages and emails, also allowing the full download of recorded data. Monitoring system...
