Veterinary syringe pump Veterinary 900B

Product catalog summary

Overview: The HY-900B Syringe Pump by Guangzhou Beaconn Medical Science Technology Co., Ltd. is a versatile medical device designed for precise infusion therapy. It offers eight infusion modes, including Rate Mode, Time Mode, Drug-Weight Mode, and more, ensuring adaptability to various medical needs.

Key Features:

Infusion Modes: The pump supports eight modes, including optional Drug Library Mode, enhancing its functionality for different medical scenarios.
Display and Operation: Features a 2.8-inch color display with dual flow rate display for intuitive operation.
Safety and Monitoring: Equipped with a comprehensive safety monitor, dual CPU, dynamic pressure system, and anti-bolus features. It also has IP34 protection and syringe plunger protection.
Connectivity: Offers optional wireless connection with HL7 data protocol for smart connectivity.
Power and Battery: Operates on AC and DC power with a built-in rechargeable lithium battery providing up to 12 hours of operation at 2ml/hr.

Technical Specifications:

Applicable Syringes: Compatible with 5ml to 60ml syringes from various brands, with customization options for 50 brands.
Accuracy: Maintains an accuracy of ±2% with correct calibration.
Flow Rates: Varies by syringe size, with a minimum step of 0.1ml/hr.
Occlusion Pressure: Adjustable settings ranging from 30 to 120 Kpa.
Alarms and Alerts: Includes multiple alarms for various operational errors and conditions, with adjustable volumes.
Bolus Functionality: Programmable bolus rates and volumes, with both automatic and manual options.
Data and Interface: Stores up to 5000 events, accessible via RS-232 interface.

Physical and Packaging Details:

Dimensions: 305mm x 130mm x 108mm, weighing 1.9kg.
Packing Size: 36cm x 20cm x 18cm, with a gross weight of 2.0kg.

Catalog excerpts

Veterinary syringe pump Veterinary 900B-1

8 Infusion modes Rate Mode,Time Mode, Drug-Weight Mode, Section Mode, First Dose Mode, Gradient Mode, Micro Mode, Drug Library Mode (Optional) Comprehensive Safety Monitor Dual CPU, Dynamic Pressure System,Anti-Bolus, IP34 Protection 12 Hours back up Battery, Syringe Plunger Protection, Intuitive Operation Flow Rate Dual display, 2.8-inch Color Display Auto Bolus & Manual Bolus Smart Connectivity Optional Wireless connection module with HL7 data protocol Guangzhou Beaconn Medical Science Technology Co.,Ltd Add: 3rd Floor,Building 4,Yixiang Technology Park,72 Nanxiang 2nd Ave,Huangpu District,Guangzhou,510663,China
