HYBRID ELECTROSPINNING TECHNOLOGY

About INOVENSO We started our academic activities in 2007 working on nanotechnologies under the Nano Fiber Membrane Group (NanoFMG). After focusing on improving Nanofiber quality during Electrospinning process, we established our born global company Inovenso in 2010. Our name is acronym of Innovative Engineering Solutions. We aimed to developed very efficient electrospinning machines and accelerate nanofiber science. We quickly become a bridge company between academia and industry and proudly contributed to hundreds of scientific projects using polymer nanofibers for wide variety of applications...

Hybrid Electrospinning Technology PE-300 uses a patented, unique “Hybrid Electrospinning Technology”. The PE-300 is our cutting-edge electrospinning device for the continuous production of nanofibers. Its major advantage is scalability, as it’s suitable for both big-scale production line as well as small-scale R&D projects. The NS Pilot Line enables high productivity for mass production of nanofibers with high-functioning 18 nozzles, in addition to energy saving mode of single nozzle function for small-scale R&D projects. Its unique design differentiates PE-300 from other devices with more flexible...

UNIQUE USER INTERFACE INM nSplnner USER FRIENDLY Specially designed control panel with user-friendly interface makes operations much easier. Operator will have the full control of all parameters. The recipes recall function enables users to save parameters and recall

Nano Spinner • Single and Multi Nozzle Operation Up to 18 Nozzles during full operation Possible option of eco mode with single nozzle Nozzles with wide variety of diameters could be used simultaneously 2 Precise syringe pumps 2 High voltage power suppliers (40kV). Each of them charges different pipe sets. Fiber Deposition Width: 300 mm Substrate Winding Speed: 0,01 m/min - 10 m/min Coating Homogeneity System: X-axis repetitive motion Stroke of Coating Homogeneity System: 10mm - 80mm Speed of Coating Homogeneity System: 5-50 mm/sec Single Nozzle Feeding: 2ml Feeding each Pipe Set: 15ml Full Loading:...

2 integrated high voltage suppliers for each of the 2 nozzle rods. 2 individually adjustable syringe pumps to infuse up to 2 solutions simultaneously.

NOZZLE HOLDER BLOCK CONTROL PANEL DRY INLET COLLECTOR SIDE EMERGENCY BUTTONS (×2) WARNING LAMP TECHNICAL DRAWING SYRINGE PUMPS POWER INLET SYRINGE PUMPS SPARE PART CONNECTIONS SYRINGE PUMPS

APPLICATION AREAS: Medicine Tissue Engineering Filtration Food Defense
