KAPSAM Biosafety Cabinet Solutions

Product catalog summary

Overview: The Class II type B2 microbiological safety biosafety cabinet is designed to provide protection for products, personnel, and the environment, allowing safe work with toxic chemicals and high pathogens. It features a HEPA filter system that ensures 100% air exhaust, maintaining a sterile working environment.

Main Material & Design Specifications:

Airflow System: 0% air recirculation, 100% air exhaust.
Main Body: Electrostatic epoxy powder-coated HRC.
Internal Working Area: AISII 304 stainless steel.
Working Floor: Removable for easy cleaning.
Working Glass: 6mm tempered, motor-controlled, anti-UV.
HEPA Filter: H14 type with 0.3 µm particle retention (EN 1822).
Additional Features: UV-C sterilization, interior LED lighting, waterproof sockets.

Control Features:

Touch-Screen Control Panel: Includes ON/OFF, emergency button, and real-time display of inflow/downflow rates and temperature.
Automatic Fan Speed Control: Based on flow rates.
Warning System: Audible and visual alerts.
Additional Controls: UV lamp, working lamp, and fan motor ON/OFF.

Optional Features:

HDGC main body, water and gas taps, rack apparatus, video camera & audio recording system.
316L stainless steel workbench, laminated windshield, auto-restart function, power failure alarm.

Technical Details:

Model Dimensions: Various external and internal dimensions provided.
Weight: Ranges from 300 kg to 375 kg.
Air Velocity: Inflow air velocity at 0.51 m/s, downflow air velocity between 0.25 – 0.50 m/s.
Filtration Efficiency: H14 HEPA filters with 99.995% efficiency for 0.3 µm particles.
Cleaning Class: < ISO 5 (EN ISO 14644-3), < Class 100 (US FED 209E).

Applications: Suitable for automated IV compounding systems, fluid dispensing pumps, pharmacy operations, IV workflow management, and sterile compounding solutions.

Manufacturer: KAPSAM HEALTH PRODUCTS LTD., located in Kocaeli, Türkiye.

Catalog excerpts

BioSafety Cabinet

Open the catalog to page 1

BioSafety Cabinet Kapsam Class II type B2 microbiological safety biosafety cabinet provides first-class protection for products, personnel and environment and allows working with toxic chemicals and high pathogens. After passing the air taken from the environment through a fine and absolute (HEPA) filter it passes through the laminator into the working area. Product protection is provided by filtered laminar airflow. Personnel protection is provided by the air barrier on the front of the device. All the air passes through the HEPA filter at high speed and is 100% exhausted. Main Material & Design...

Open the catalog to page 2

Touch-Screen Control Panel Optional Features Turn ON/OFF button Electrostatic powder-coated HDGC main body Emergency button Color Touch screen with TFT microprocessor On-Screen display of real-time inflow/downflow rates and temperature Automatic fan speed control based on flow rates Rack Apparatus (for hanging serum bags) Video Camera & Audio Recording System 316L stainless steel workbench Front window up/down movement control Audible and visual warning system Windshield adjustment pedal Auto-restart function Working Lamp ON/OFF Power failure alarm Fan Motor ON/OFF Quickstart, automatic speed...

Open the catalog to page 3

Comprehensive Solutions for Sterile Compounding & IV Infusion Automated IV Compounding Systems (TPN / ONCO / CIVA) Automated Fluid Dispensing Pump Pharmacy Operation & Order Entry Software (CPOE) IV Workflow Management System (IV-WMS) IV Compounding & Infusion Disposables Modular Cleanrooms & Accessories Biosafety & LAF Cabinets KAPSAM HEALTH PRODUCTS LTD. Cumhuriyet Mah. Ismet Inonu Cad. No: 57 41420 Cayirova, Kocaeli - Türkiye +90(262) 2908801

Open the catalog to page 4
