Contents Proximal Illumination SYSTEM OVERVIEW TOTAL OVERVIEW Distal Illumination SYSTEM OVERVIEW TOTAL OVERVIEW Other Products TELESCOPE GUIDE SHEATHS FULL LUMEN BRONCHOSCOPES AND TRACHEOSCOPES

Rigid Bronchoscopy Rigid bronchoscopy has been performed for more than 100 years, and in the course of this long history, considerable advancements have been made. KARL STORZ has played a major role in these developments and today offers extensive experience in this area. The rigid technique has many advantages and provides optimal examination conditions for general anesthesia. Rigid bronchoscopy is the method of choice for foreign body removal and is absolutely essential for stopping major bleeding. In addition, flexible bronchoscopes can be inserted through the rigid tube as often as desired...

Interventions Hemostasis Tumor resection An important indication for the use of rigid bronchoscopy is heavy bleeding, which can occur in the bronchial system. To stop bleeding, a rigid bronchoscope is employed using various techniques for hemostasis. Lung tumor tissue is removed with the help of rigid bronchoscopes and matching instruments. Depending on the size of the tumor, bronchoscopes with a large diameter may be necessary. Removal of foreign bodies Bronchoalveolar lavage The rigid bronchoscope is used to remove large foreign bodies in the trachea or the bronchi. Rigid bronchoscopy is also...

Proximal Illumination Universal Bronchoscope, size 6.5, outer diameter 9.2 mm, inner diameter 8.5 mm, length 43 cm Universal Bronchoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 43 cm Universal Bronchoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 43 cm Full Lumen Operating Bronchoscope, size 11, outer diameter 11.2 mm, inner diameter 10.5 mm, distal with air holes and 45° oblique beak, length 43 cm, color code: green Full Lumen Operating Bronchoscope, size 12, outer diameter 12 mm, inner diameter 11 mm, length 43 cm Full Lumen Operating Bronchoscope,...

Proximal Illumination Universal Tracheoscope, size 6.5, outer diameter 9.2 mm, inner diameter 8.5 mm, length 33 cm Universal Tracheoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 33 cm Universal Tracheoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 33 cm Full Lumen Operating Tracheoscope, size 12, outer diameter 12 mm, inner diameter 11 mm, length 33 cm Full Lumen Operating Tracheoscope, size 14, outer diameter 14 mm, inner diameter 13 mm, length 33 cm Full Lumen Operating Tracheoscope, size 14, outer diameter 14 mm, inner diameter 13 mm, distal...

Proximal Illumination Prismatic Light Deflector, autoclavable, with connection for fiber optic light cable Prismatic Light Deflector, autoclavable, with connection for fiber optic light cable Blind Plug, to close the prismatic light deflector adaptor at the bronchoscope Sealing Cap, with window Rubber Telescope Guide FLUVOG Adaptor, with observation window, sealing cap with rubber seal and a window with opening, adjustable Vent Plug, for ventilator attachment Injection Cannula, LUER-Lock, outer diameter 3.5 mm Injection Cannula, double lumen, outer diameter 2.5 mm, length 62 mm Instrument Guide,...

Proximal Illumination Art. no. Size in cm Telescopes Optical Forceps and Instruments

Proximal Illumination HOPKINS® Straight Forward Telescope 0°, diameter 5.5 mm, length 50 cm, autoclavable, fiber optic light transmission, color code: green HOPKINS® Forward-Oblique Telescope 30°, diameter 5.5 mm, length 50 cm, autoclavable, fiber optic light transmission incorporated, color code: red Universal Bronchoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 43 cm Universal Bronchoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 43 cm Universal Bronchoscope, size 6.5, outer diameter 9.2 mm, inner diameter 8.5 mm, length 43 cm Prismatic Light...

Telescope Guide Sheath, for use with Bronchoscopes 10318BP, 10318CP, 10318DP, 10318ER, 10318GL, 10318FL and HOPKINS® Telescopes 10320AA, 10320BA Optical Forceps, large jaws, alligator, serrated, double action jaws, working length 45 cm, with spring-action handle, incl. cleaning adaptor, for use with HOPKINS® Telescopes 10320AA, 10320BA Optical Forceps, bean jaws, blunt grooved, double action jaws, working length 45 cm, with spring-action handle, incl. cleaning adaptor, for use with HOPKINS® Telescopes 10320AA, 10320BA Optical Forceps, round, spoon-shaped, double action jaws, working length 45...

Proximal Illumination Universal Bronchoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 43 cm Universal Bronchoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 43 cm Universal Bronchoscope, size 6.5, outer diameter 9.2 mm, inner diameter 8.5 mm, length 43 cm Universal Tracheoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 33 cm Universal Tracheoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 33 cm Universal Tracheoscope, size 6.5, outer diameter 9.2 mm, inner diameter 8.5 mm, length 33 cm Full Lumen Operating...

10101FA Prismatic Light Deflector, autoclavable, with connection for fiber optic light cable 10101HA Prismatic Light Deflector, autoclavable, with connection for fiber optic light cable 10315RV Blind Plug, to close the prismatic light deflector adaptor at the bronchoscope 10314BM Sealing Cap, with window 10314BN Rubber Telescope Guide 10314P FLUVOG Adaptor, with observation window, sealing cap with rubber seal and a window with 10924E Vent Plug, for ventilator attachment 10318K Injection Cannula, LUER-Lock, outer diameter 3.5 mm 10318KD Injection Cannula, double lumen, outer diameter 2.5 mm,...

Distal Illumination Universal Bronchoscope, size 8.5, outer diameter 11.2 mm, inner diameter 10.5 mm, length 43 cm, consisting of: 10318B Universal Bronchoscope 10318L Fiber Optic Light Carrier Universal Bronchoscope, size 7.5, outer diameter 10.2 mm, inner diameter 9.5 mm, length 43 cm, consisting of: 10318C Universal Bronchoscope 10318L Fiber Optic Light Carrier
