Hydrogen Peroxide Plasma Sterilizer LPP-102

Hydrogen Peroxide Plasma Sterilizer LPP-102

Product catalog summary

Description: The Labotemp Hydrogen Peroxide Plasma Sterilizer LPP-102 is a 100L low-temperature sterilizer designed for delicate medical instruments that cannot endure high temperatures. It uses hydrogen peroxide vapor, vacuum conditioning, and plasma activation to sterilize while maintaining the integrity of heat-sensitive devices. Operating at approximately 50±5°C, it is ideal for sterilizing endoscopes, ophthalmic instruments, and other precision medical equipment.

Features: The LPP-102 includes an intelligent control platform with automated cycle management, real-time monitoring, and one-touch operation. Its rectangular chamber design enhances loading efficiency and ensures uniform sterilant distribution. The system converts residual hydrogen peroxide into water vapor and oxygen, leaving no harmful residues. It also features integrated safety diagnostics, automatic fault detection, and a corrosion-resistant chamber for reliable long-term use.

Specifications:

Capacity: 100L
Sterilization Temperature: 50 ± 5°C
Power Supply: 380V, 220V / 50Hz
Power Consumption: 3.6 kW
Sterilization Medium: Hydrogen Peroxide Vapor and Plasma
Control System: PLC Control
User Interface: Touch Screen HMI
Data Storage: USB (U Disk) Storage Function
Chamber Material: Aluminum Alloy
Fault Detection: Automatic Fault Detection and Cause Display
Sterilization Monitoring: Real-Time Process Monitoring
Hydrogen Peroxide Purification Device: Included
Environmental Protection: No Harmful Residues, No Drainage or Exhaust Required
Inner Chamber Size: 450 × 400 × 750 mm
External Dimensions: 800 × 1050 × 1750 mm
Package Size: 1240 x 950 x 1980mm

Applications: The sterilizer is suitable for heat- and moisture-sensitive medical devices in hospitals, surgical centers, endoscopy units, ophthalmology clinics, and research laboratories. It is used for sterilizing rigid and flexible endoscopes, laparoscopes, hysteroscopes, laryngoscopes, ophthalmic instruments, electrosurgical accessories, metal tools, glassware, and silicone-based devices.

Catalog excerpts

Hydrogen Peroxide Plasma Sterilizer LPP-102-1

LABOTEMP Your Partner in Temperature Precision Hydrogen Peroxide Plasma Sterilizer LPP-102 www.labotemp.com | [email protected]

Open the catalog to page 1

Hydrogen Peroxide Plasma Sterilizer LPP-102-2

Description: Labotemp Hydrogen Peroxide Plasma Sterilizer LPP-102 is a 100L low temperature plasma sterilizer engineered for safe and efficient sterilization of delicate medical instruments that cannot withstand conventional steam autoclave temperatures. Utilizing advanced H₂O₂ sterilizer technology, the system combines hydrogen peroxide vapor, vacuum conditioning, and plasma activation to eliminate microorganisms while preserving the integrity of heat-sensitive devices. With an operating temperature of approximately 50±5°C, it is well suited for sterilizing endoscopes, ophthalmic instruments,...

Open the catalog to page 2

Hydrogen Peroxide Plasma Sterilizer LPP-102-3

□ Gas Plasma Technology: Effective sterilization with excellent material compatibility □ Low Temperature Processing: Protects sensitive instruments from thermal damage

Open the catalog to page 3

Hydrogen Peroxide Plasma Sterilizer LPP-102-4

Residue-Free Sterilization PLC-Based Intelligent Control System with touchscreen interface enables convenient parameter setting and cycle management. USB Data Storage Function allows sterilization records and operational data to be saved for traceability and documentation. Hydrogen Peroxide Injection Control ensures accurate sterilant dosing to optimize consumable usage and process consistency. Aluminum Alloy Sterilization Chamber offers excellent corrosion resistance, rapid heat transfer, and uniform temperature distribution. Rectangular Chamber Configuration maximizes usable loading space and...

Open the catalog to page 4

Hydrogen Peroxide Plasma Sterilizer LPP-102-5

research laboratories. Used for processing rigid and flexible endoscopes, laparoscopes, hysteroscopes, laryngoscopes, ophthalmic instruments, electrosurgical accessories, metal tools, glassware, and silicone-based devices requiring residue-free low-temperature sterilization with validated infection control. Your Partner in Temperature Precision 144 E, Midwest Avenue, Casper WY 82601, USA Website: www.labotemp.com | Email: [email protected]

Open the catalog to page 5
