EVISA Lubricated Rotary Vane Vacuum Pumps - Technical Summary

1. Overview

The document provides comprehensive technical specifications, operational features, maintenance guidelines, and accessory options for the EVISA series of lubricated rotary vane vacuum pumps. These pumps are designed for continuous industrial and healthcare applications, offering robust, silent operation from atmospheric pressure down to ultimate vacuum levels.

2. Specifications and Performance

• Vacuum Capability: Achieves absolute end vacuum levels as low as 6x10^-2 mbar (approx. 4.5x10^-2 torr), depending on model and gas ballast settings.
• Pumping Speed: High pumping speeds across models (E25.R, E40.R, E150.R, E200.R, E300.R), with nominal flow rates ranging from ~25 m³/h to 360 m³/h, measured per PNEUROP 6602 standards at 20°C.
• Water Vapor Handling: Adjustable gas ballast (closed, partially opened, fully opened) allows effective pumping of humid gases and prevents condensation inside the pump.
• Noise Levels: Low noise emissions (from ~44 dB(A) to 77 dB(A) depending on model), enabling installation near operators.
• Oil: Pumps are delivered with MV99S 100% synthetic oil for durability and heavy-duty use; oil capacities vary by model (1 to 2.2 liters for smaller pumps, larger volumes for bigger models).
• Electrical Motors: IE3 efficiency motors with power ratings from 0.75 kW to 10 kW (or 1 to 13.5 HP), available in multiple voltage and phase configurations tailored to geographic regions (Europe, USA, Asia, South America, Middle East, Japan).
• Connections: Standard inlet/outlet connections include 1" or 2" BSP/NPT threads, with optional DN25, DN40, or DN50 ISO-KF flange adapters.

3. Design and Features

• Single-stage rotary vane design optimized for compactness, robustness, and low noise.
• Integrated oil mist filter on exhaust reduces emissions and environmental impact.
• Gas ballast adjustment controls water vapor load, enhancing pump longevity and performance.
• Designed for easy onsite maintenance without disconnecting piping.
• Robust construction suitable for continuous industrial operation.

4. Versions and Special Models

• Standard and high vacuum (HV) versions available.
• Oxygen-compatible versions using Fomblin oil for safe operation with oxygen.
• Specialized models optimized for condensable vapor pumping and enhanced water vapor handling (EVISA H2O versions).

5. Accessories and Options

• Oil level safety switches with float and timer boxes for operational safety.
• Temperature safety devices including NC bimetal switches (opens at 120°C) and PT100 sensors.
• Various suction filters with paper, polyester, or carbon cartridges.
• Vacuum gauges and adjusting valves mounted on T-square connectors.
• Liquid traps with cylinders made of plexiglass, Pyrex, or stainless steel, with mechanical float options.
• Pyrex bottles in multiple volumes (250 ml, 500 ml, 1000 ml) for trap assemblies.
• Automatic electro-pneumatic and electrical drains with control boards.
• Vacuum and suction hoses with no-return valves, available in various lengths.
• Base frames and elevated base frames for mounting one to three pumps.
• Direct starters with or without regulation contacts, including warm-up and degassing system options.
• Additional accessories such as rubber feet, exhaust adapters, wall fixing brackets, and DN50 KF connection adapters.

6. Maintenance Guidelines

• Routine maintenance recommended every 3,000 operating hours, including gasket replacements and oil mist filter servicing.
• Preventive maintenance advised every 12,000 hours to ensure longevity and performance.
• Options for silicone or Viton O-rings on oil mist filters to suit different maintenance needs.
• Special maintenance procedures and kits available for oxygen-compatible pumps.

7. Performance Curves and Data

Performance graphs illustrate pumping speed versus absolute pressure for 1000-liter vessels under various gas ballast settings and operating frequencies (50 Hz and 60 Hz). These curves demonstrate the pumps’ ability to maintain high pumping speeds and reach low vacuum levels efficiently under different conditions.

8. Applications and Usage

EVISA pumps are suitable for diverse industrial and healthcare applications requiring reliable vacuum generation. Their silent operation and compact design allow installation near operators and integration into machinery. Effective water vapor handling makes them ideal for processes involving humid gases.

9. Critical Information and Recommendations

• Specifications are subject to change without notice; users should verify current data before ordering.
• Use of MV99S 100% synthetic oil is strongly recommended to ensure pump durability and warranty compliance.
• Adjust gas ballast settings according to process requirements to optimize water vapor handling and vacuum performance.
• Adherence to recommended maintenance intervals is essential for reliable operation and extended pump life.
• Consult manufacturer or distributor for special versions, oxygen-compatible models, and booster mounting options.

Electrical and Electronic Equipment Calibration - Technical Summary

1. Overview and Context

The document also includes a section related to technical specifications, calibration procedures, and operational guidelines for electrical or electronic measurement and control equipment. This likely pertains to power supplies, signal processing, or instrumentation systems.

2. Specifications and Parameters

• Voltage levels specified include 0.6 V, 1 V, 1.1 V, and 1.7 V, with associated power ratings (e.g., 100 W, 200 W).
• Timing parameters such as 100 ms, 710 ms, and 1000 ms indicate pulse durations or measurement intervals.
• Environmental conditions referenced include temperatures around 20°C and power dissipation values.
• Measurement units include decibels (dB), energy (E), and temperature in Kelvin (K), indicating precise calibration standards.

3. Procedures and Testing

• Calibration and verification procedures involve use of reference signals and controlled test conditions.
• Instructions cover device tuning to meet performance criteria, monitoring output stability, and response to input variations.

4. Standards and Norms

• Compliance with national or international standards is emphasized, with references to specific codes.
• Quality assurance processes focus on repeatability, accuracy, and traceability.

5. Recommendations and Best Practices

• Maintain equipment within specified operational parameters to ensure reliability and safety.
• Perform periodic recalibration and monitoring to prevent drift and degradation.
• Keep thorough documentation for traceability and quality control.

6. Data and Measurement Interpretation

Numerical data includes voltage, timing, power, and environmental parameters supporting equipment validation and performance assurance.

7. Limitations and Constraints

• Operational limits on voltage, current, temperature, and timing are specified to avoid damage or malfunction.
• Adherence to these limits is critical for safe and effective operation.

8. Summary

This section provides detailed technical guidance for calibration, testing, and operation of electrical/electronic measurement equipment, emphasizing precision, compliance with standards, and best practices for maintenance and quality assurance.
