THE NEW LIGHTING AND MEDICAL SUPPLY SYSTEMS F O R H E A LT H A N D C A R E
15Pages

LIGHT MAKES YOU FEEL GOOD! Everybody needs light; and modul technik provides it to those who need it most! Since our companies founding in 1984, lighting has been a fundamental part of our product range. The majority of our products contain lighting components which are always of the highest quality. From now on we will be going one step further and are offering our customers a new lighting package! As of today, modul technik will be taking over all medical products from Zumtobel, one of the leading providers of professional lighting concepts worldwide. This will expand our product range in...

PICTOGRAMS General lighting The directed indirect component provides general lighting of at least 100 lx. Sophisticated lighting tech nology ensures almost 100 % em naion of the light, and thereby a t provides particularly effective general lighting even in the depth of the room. Moreover, glare is avoided and a pleasant room impression is created, conveying calm and relaxation. Reading light The reading light provides an illuminance level of at least 300 lx. Precise direc ion of light makes sure that other pat tients in the room who need rest are not disturbed. This is ensured by...

188 belia LED 1 Micro-vane lighting technology 2 Indirect light: T16 or LED L= 1255 mm 3 Direct light: T16 or LED 4 Prismatic diffuser SUCCINCT DESIGN, WARM RADIATION A luminaire without edges and corners, yet clear and noticeable: the lighting technology of the belia single-bed luminaire is incorporated within a particularly flowing design that satisfies requirements for more homeliness in care environments. The rounded forms appear warm and friendly and uniform curves provide peace of mind for the observer. And the form underlines the function: thanks to the distinct subdivision of the...

Room lighting  belia really creates lighting conditions for wellbeing. The room is fed with indirect light right into its corners, and longitudinal prisms within the diffuser are a clever detail with great effect. They restrict a direct view into the luminaire and instead create a feeling of well-being with optimum light distribution. belia BELIA IS ADJUSTABLE Compatible and extremely contact-friendly – optional supply elements for belia belia has, at least on the outside, the dimensions of a classical single-bed luminaire and yet at a length of 580 mm offers space for several supply...

curea and curea LED 1 Waveguide 2 Indirect light: T16 or LED 3 Direct light: T16 or LED 4 Night light E14 or LED curea SLC® Waveguide Waveguide technology is based on a light guide made of acrylic glass with an applied microprismatic structure, and ensures se ecti e directil v on of light. It produces largely low-glare light and pleasant and uniform room lighting. Direct viewing of the light source is prevented and annoying reflections on smooth surfaces and LCD screens are minimised. curea exploits the properties of the special SLC® linear wave uide g which tapers outwards. The light is...

sinus SL single-bed luminaire 1 Room lighting 2 Reading light/examination lighting 3 Data cables 4 Low-voltage cable duct 5 Power current cable duct SLIMLINE DESIGN WITH GREAT POTENTIAL With its understated, slimline stylistic idiom, the sinus SL single-bed LED luminaire presents itself as a flexible technological supply system and design element in one unit. Equipped with top-quality LED technology, the luminaire is available in a standard length of 1150 mm for single beds and is suitable for configurations of up to 6 m for multi-bed rooms. Individual switching and dimming is possible just...

FREEDOM OF DESIGN ALL THE WAY DOWN THE LINE Single-bed luminaire As a visually attractive single-bed luminaire, pureline II is bound to impress thanks to its plain lines, unruffled elegance and healthful light. For the patient, it brings a note of homeliness into the often unfamiliar environment of the hospital. Even as a single-bed luminaire, pureline II easily meets the requirements placed on perfect general, reading, examination and night lighting. A choice can be made between versions fitted with contemporary LED technology or with T16 fluorescent tubes. 1

pureline II TOP MARKS FOR LIGHTING QUALITY BENEFICIAL COMBINATION OF SEVERAL LIGHT SOURCES „The right amount of the right light at the right time.“ Le Corbusier Whether at the patient’s instigation, brought about by the staff or unexpec edly quickly – as t soon as the situation in the care room changes, pureline II can respond by changing its appearance. Extremely diverse lighting requirements ranging from daily ward rounds through to everyday activities such as reading, eating or communicating can be catered for by finely coordinated combinations of indirect room light and direct lighting....

pureline II DESIGN WITH INNATE VALUES GANZEN LINIE GESTALTUNGSFREIHEIT AUF DER „pureline II – reduced in its dimensions and form to a minimum, yet in its function extended far beyond what is usual – builds a bridge to a space-creating design element, which in its purity and formal elegance opens up new possibili ties of interior design.” The lighting concept can lend a room a cosy feel, especially in medically used areas where architecture and equipment have to fulfil a large number of functional tasks. pureline II integrates the lightng and medical supply unit into the ari chitecture as a...

„sinus is a technological supply system for nursing areas. Owing to its plain design as well as the flexibility of its functions, the system will adapt to the most varied of interiors. The carefully manufactured details and the surface finish provide for top comfort.” sinus Design sinus ARCODE_A. Ciotti – E. Molinaro sinus supply unit 1 Room light 2 Reading/examination light 3 Medical gases 4 Data cables 5 Low-voltage cable duct 6 Mains power cable duct 7 Bracket for accessories MINIMALIST DESIGN. MAXIMUM FUNCTIONALITY. The patient’s well-being greatly influences the progress of recovery....
