Optos Ultra-widefield Retinal Imaging with optomap-guided SD-OCT MonacoPRO. The only device delivering opto map® color rg, Sensory Retina, Choroidal, green af, and high resolution SD-OCT— with 5-modality bilateral capture in just 90 seconds. optomap color Sensory Retina Sensory Retina optomap Choroidal optomap green af optomap Choroidal

Fast, Comprehensive Imaging MonacoPro allows visualization of multiple image modalities at the same time, enabling a practitioner to detect pathology with a single click. Only MonacoPro provides ultra-widefield SLO and SD-OCT in a single, seamless platform. • Unmatched Diagnostic Capability ONH Topography Combined 200º single-shot optomap imaging with spectral-domain OCT has been reported to support the detection of 29.4% more macular pathology compared to fundus imaging alone.1 • Clinically Validated Performance Retinal Topography Supported by over 3,000 clinical studies across 300+ diseases,...

Fast, Comprehensive Imaging and Analysis RETINAL THICKNESS ILM and RPE are automatically detected and marked. Retinal thickness is measured and displayed in a color map, and numeric values are provided in an ETDRS grid overlay. The MonacoPro analysis tools automatically segment, measure, and display key parameters. Results are shown in relation to the comprehensive Reference Database population. Parameter table with RDB comparison RDB Legend GCC is automatically segmented and measured from the ILM to the IPL. Thickness measurements are displayed in a color map and grid overlay. ONH RNFL THICKNESS...

MonacoPro Pathology and Disease Detection Diabetic Retinopathy with DME 200° single-shot optomap imaging combined with MonacoPro SD-OCT delivers unparalleled retinal imaging capabilities to assist in disease detection with precision and efficiency. Glaucoma hole Patients with diabetic retinopathy can be evaluated for both central and peripheral changes on ultra-widefield optomap color rg, as peripheral lesions are indicative of high risk for disease progression.4 MonacoPro Retina Topography can be used to evaluate macular edema, as seen in this case where hard exudates and cystic changes are...

Image Capture Features • Non-mydriatic, with a minimum 2mm pupil1 2 3 4 5 • cSLO imaging through most cataracts6 • 3-in-1 Color Depth Imaging™ provides important clinical data from the retinal surface through the choroid • Optos,Advance™ Image Management software streamlines image review and consultations • A comprehensive Reference Database (RDB) enables results of OCT analysis to be shown in relation to 1%, 5%, 95%, and 99% of the RDB population • MonacoPro is equipped with AreaAssist, a tool designed to improve the efficiency of retinal imaging workflows by enabling users to automatically...
