Helix3D Hip Joint System The Otto Bock brand stands for trend-setting innovations in prosthetics. The new Helix3D Hip Joint System also is a trend-setter. It sets new standards in terms of safety, dynamics, and comfort, and redenes the mobility of hip amputees.

Open the catalog to page 2

Let's Open up New Dimensions Thanks to unique functions, Helix3D offers the user noticeable advantages: The patented multi-axis joint structure Time • produces a three-dimensional hip movement to compensate for pelvic rotation and promotes a symmetrical and natural gait pattern (Fig. 1). • allows for leg length reduction during the swing phase with the aim to reduce the risk of falling and thereby to increase functional safety. • ensures optimal sitting characteristics and reduces pelvic obliquity to a minimum. Natural pelvic rotation Sound hip joint • makes a large flexion angle possible,...

Open the catalog to page 3

Indication and Field of Application for hip disarticulation and hemipelvectomy amputees. It offers amputees of all age groups maximum safety and comfort for a wide range of everyday The Helix3D Hip Joint System is suitable activities. Recommended according to the Otto Bock MOBIS® Mobility System for amputees with Mobility Grades 2 and 3 Maximum body weight: 100 kg/220 lbs (restricted outdoor walkers, unrestricted outdoor walkers). Helix3D – Systematic Fitting The Helix3D Hip Joint's functions are specially adapted to 757L16-2 the characteristics of selected Otto Bock components. The...

Open the catalog to page 4

Certification Workshop for the Helix3D Hip Joint System Are you already a C-Leg® certied prosthetist? Are you, What You Will Learn: in addition, interested in carrying out professional patient • A special plaster cast technique for the Helix 3D Hip ttings with the new Helix3D Hip Joint? Then simply participate in one of our certication workshop. This workshop is a prerequisite for carrying out independent ttings with the 3D Joint • Correct component selection and alignment instructions • Biomechanics and functionality of the Helix3D Hip Joint System Contents of the Workshop After...

Open the catalog to page 5

Patents The 7E10 is covered by the following patents: China: ZL 00121494.2 Germany: D.B.P. DE 199 35 203 Japan: Patent No. JP 3 708 797 Russia: RU 2 222 291 USA: Patent US 6,322,594 European Patent: EP 1 072 240 in CH, DE, ES, FR, GB, IT, NL and SE, Otto Bock HealthCare GmbH Max-Näder-Straße 15 · 37115 Duderstadt/Germany · Phone +49 5527 848-1424 · Fax +49 5527 72330 · export@ottobock.de · www.ottobock.com Technical modifications reserved. Patents pending in Brazil and Germany.

Open the catalog to page 6
