TurboMatrix Headspace and Headspace Trap Samplers for GC

Headspace Gas Chromatography—for applications involving the solvent-free extraction of volatile compounds, it’s an unsurpassed technique, eliminating the time-consuming steps and risk of human error associated with other GC sample-preparation methods. Engineered to deliver unparalleled precision, sensitivity and productivity in a broad range of specialized applications—including forensics, food and beverage, pharmaceuticals and environmental—TurboMatrix™ Headspace (HS) and Headspace Trap samplers are the clear choice for laboratories seeking outstanding throughput and precision. The best...

Open the catalog to page 2

TurboMatrix Headspace and Headspace Trap Samplers for GC - 3

Designed for superior simplicity and throughput, TurboMatrix systems set the standard for productivity in the analysis of volatile compounds. Touchscreen graphical user interface Dynamic leak check A clear, intuitive, multilingual touchscreen interface puts you in total control of every part of your sample path—from vial to column. With just a few touches, you can select and review methods, set parameters and initiate analyses. By giving you the option to constantly monitor pressures throughout the entire system, TurboMatrix samplers can verify the integrity of each vial’s seal—giving you...

Open the catalog to page 3

TurboMatrix Headspace and Headspace Trap Samplers for GC - 4

TurboMatrix Headspace samplers utilize an array of proven technologies to ensure they deliver outstanding precision in any application. The result is superior repeatability for every sample in every run. Ultra-stable, uniform thermostatting Featured in the TurboMatrix HS-40 and HS-110, a 12-position oven delivers the ultimate in precision thermostatting. Built around a substantial 2-kilogram aluminum alloy block, the oven distributes heat with exceptional uniformity. This block rotates within a stationary heater sleeve, eliminating temperature variation and providing highly consistent vapor...

Open the catalog to page 4

TurboMatrix Headspace and Headspace Trap Samplers for GC - 5

Thanks to pressure-balanced technology, TurboMatrix Headspace samplers deliver exceptional performance in the analysis of your samples. Greater sensitivity can be achieved because the system offers an array of unique features and benefits: • ero dilution liner ensures sample gas passes undiluted from the transfer line into the column Z • o fractionation due to pressure and temperature changes experienced with syringe-based systems N • ample is introduced rapidly and as a sharp band to the GC, resulting in sharper peaks S • inimal number of hardware components come into contact with the...

Open the catalog to page 5

TurboMatrix Headspace and Headspace Trap Samplers for GC - 6

0.40 0.10 0.20 0.30 0.40 • urboMatrix HS-110 enables a full magazine of 110 vials to be T processed in just 3 hours 0.50 0.60 0.50 0.60 0.80 acetone i-propanol ethanol 0.70 0.90 1.00 1.10 1.20 0.70 0.90 1.00 1.10 1.30 1.20 n-propanol 0.30 ethanol 0.20 methanol 0.10 acetaldehyde 0.00 0.00 • elivers confirmatory results within 90 seconds for ethanol and other D required analytes for blood analysis i-propanol • ndustry standard for the determination of alcohol levels in blood I acetone methanol TurboMatrix Headspace systems are the perfect choice for detecting volatiles in biological fluids....

Open the catalog to page 6

TurboMatrix Headspace and Headspace Trap Samplers for GC - 7

No two laboratories have identical demands. That’s why the TurboMatrix line offers a range of configurations, all engineered to deliver the highest standards of performance. No matter which system you choose, you can count on complete compatibility with the entire PerkinElmer Clarus family of gas chromatographs, as well as GC instruments from every other major manufacturer. So you can enhance your laboratory’s analytical capabilities without replacing existing systems. TurboMatrix HS-16 Full software compatibility A Headspace sampler designed to meet your needs and exceed your expectations....

Open the catalog to page 7

TurboMatrix Headspace and Headspace Trap Samplers for GC - 8

Nothing has a greater impact on productivity or return on investment than instrument uptime. And no one does more to ensure your chromatography systems perform day in and day out than PerkinElmer. With OneSource Laboratory Services, you have the world’s largest and most respected global service and support network at your disposal. We go beyond just maintenance and repair of instrumentation. We incorporate laboratory asset management as part of our customers’ business equation—a partner with proven results in improving efficiencies, optimizing operations and providing cost certainty across...

Open the catalog to page 8
