MiniBox+™
MiniBox+™
- Ease of Use: The MiniBox+ is fully automatic, requiring minimal setup and providing automatic lung volumes and DLCO measurements. It features an intuitive user interface and customizable reports.
- Accuracy: Clinically validated in over 500 patients across 8 medical centers, the device offers accurate and repeatable measurements, minimizing technician bias.
- Innovative Design: The device is gasless and cabinless, reducing patient discomfort and allowing testing for obese, wheelchair-bound, or bedridden patients.
- Portability: Lightweight with a small footprint, it includes an optional cart for easy transport.
- Pediatric Use: Suitable for children from age 5, though reference values for DLCO may not be available for children under 7.
- Compliance: Fully compliant with ATS/ERS guidelines, covering spirometry, lung volumes, and diffusing capacity.
- Volume and Flow Accuracy: ±2% and ±2.5% or 50 mL/s respectively.
- Flow and Pressure Range: ±14 L/s and ±1 PSI, 7 kPa, bi-directional.
- Standards Compliance: IEC 60601-1 and IEC 60601-1-2.
- Physical Dimensions: 510x470x310 mm, weighing 8 kg.
- Gas Analyzer: Infrared spectrometer with automatic calibration and a response time of 85 ms.
Catalog excerpts
Complete Pulmonary Function Testing. Because Spirometry is just not enough. Easy to operate with minimum setup. Fully automatic Lung Volumes and DLCO measurements. All results automatically generated. Clinically validated in over 500 patients at 8 medical centers, based on comparative data from leading body plethysmography devices. With our innovative, easy-to-use, and patient-friendly technology, lung function testing is now easily accessible to all. Also available in MiniBox configuration for spirometry and lung volumes only
Open the catalog to page 1
MiniBox+ Complete, All-in-One Pulmonary Function Testing (PFT) Desktop Plethysmography, Spirometry & Diffusion Testing Easy to use, MiniBox+ provides accurate and repeatable, fully automatic measurements of Total Lung Capacity (TLC) and Residual Volume (RV), as well as Spirometry and Single Breath CO Diffusion (DLCO). FULLY COMPLIANT WITH ATS/ERS GUIDELINES: FULLY AUTOMATIC LVM AND DLCO Manual measurement optional ACCURATE & REPEATABLE Automatically generated results minimize technician bias Complete set of 30+ parameters including FEV1, FVC, SVC, MVV LUNG VOLUMES Same volumes as body plethysmography...
Open the catalog to page 2
MiniBox+ Technical Specifications With just 60 seconds of tidal breathing required for Lung Volume Measurements, this gasless, cabinless system provides maximum patient comfort. Automatic zeroing of analyzers before each measurement No stabilization time for plethysmography Warm-up time for analyzer less than 10 min Flow accuracy Flow range Pressure range Volume accuracy Dynamic resistance at 12L/s (spirometer) Standards Compliance Electrical Volume Gas graph for diffusion measurement Fast analyzer with response time t0-90 in less than 85 ms FLOW VOLUME Valve Closing duration Electrical Power...
Open the catalog to page 3
MiniBox+ meets ATS/ERS Guidelines. And goes beyond. American Thoracic Society/European Respiratory Society Guidelines MiniBox+ delivers accurate TLC measurement with desktop convenience Across a large, diverse population of healthy, obstructive and restrictive patients, the MiniBox provided accurate results in measuring TLC in comparison to market leading Body Plethysmography providers (TLC Pleth). Multi-center study 434 subjects 6 leading medical centers Compared with 3 different Body Box devices All ages, respiratory disorders, genders, severities, lung volumes Study results High correlation...
Open the catalog to page 4All PulmOne catalogs and technical brochures
MiniBox+ Brochure4 Pages
