Piranha Specifications Easy & Fast X-ray Quality Control Fast for Real A Complete QA Solution Instantly Everything happens in a flash! The Piranha product line is quick, The Piranha comes ready-to-use with everything you need Ocean software is quick and therefore your daily QA-work will go included. It is really an all-in-one multifunction meter. Connect quickly. Ocean can perform instant real-time analysis during your to your computer wireless or via USB and you have a complete measurements. Ocean also prepares a report in the background QA-system! The number of Piranha models available ensures that as you go. So when the work is done, if you want a complete you only pay for what you need. As your needs grow, you have report of your work – just press print! unlimited ability to upgrade your Piranha. Use your tablet/laptop as both an interactive display during the measurements and as a powerful analysis tool when you are back at the office. All your measurements, along with the result and the report will be stored inside your tablet or laptop. No unnecessary, time-consuming data-transfer at the end of the day. Position Check Piranha has a unique feature that makes it possible to check the position of the detector before measuring. By using the “Position Check” function, you can verify that the detector area is fully irradiated. Possible field inhomogeneities are also neutralized. Simply Plug n Play Everything happens automatically – just plug n play. The Quick Check can almost feel what you are about to do. The Quick Check feature identifies your probe and selects the optimum Piranha settings for your measurements. It can also be programmed to always start with the kind of set up that you usually start your QA-work with. There is really not much you have to think about before you begin – sit back and let the Piranha do the work! RTI Dose Probe The RTI Dose Probe is an external dose probe, designed to perform very low dose rate measurements for instance on image intensifiers. To avoid or minimize interference with Automatic Exposure Control on X-ray equipment, the probe is very small. This also enables to fit it into the table bucky. Since it is a solid-state detector, no corrections for pressure or temperature are needed. Neither is bias voltage. With the extra ordinary sensitivity of the A Piranha Never Forgets external Dose Probe it is even suitable for scatter and leakage During the measurements you will only see the desired values on your tablet or laptop but since the Piranha continues to work behind the scenes, you always have access to all of the data from each measurement. This enables you to perform for instance 2024.08 trend analysis and study the history of each X-ray equipment – even months after you have completed your measurements. RTI Group North America 33 Jacksonville Road, Bldg. 1

INDEPENDENT X-RAY QUALITY ASSURANCE Database Support Trend Analysis Interface Type Detector Position Check Simultaneous Dose Measure Bluetooth Range Power Source Battery Life Ocean QA Platform for Complete X-ray QA Rechargeable Li ion battery External power supply Piranha R/F Specifications Tube Potential 35-160 kV ±1.5% Min dose rate 0.1 |_iGy/s Trigg level 40 nGy/s Battery Tested According to UN 38.3 Resolution Bandwidth Effective Time Memory Unlimited Min dose rate 10 |_iGy/s Min dose rate 10 |_iGy/s Waveforms Resolution Bandwidth kV Bandwidth Dose Rate Extended Warranty Up to 10 years Calibration...

Piranha Mammography Specifications Tube Potential 45-155 kV ±1.5% Tube Potential 18-49 kV ±1.5% or 0.7 kV (W/Al) Min dose rate 0.1 |_iGy/s Min dose rate 0.2 |_iGy/s Resolution Bandwidth Effective Time Waveforms Resolution Bandwidth kV Bandwidth Dose Rate Resolution Bandwidth Effective Time Min dose rate 0.1 |_iGy/s Min dose rate 0.1 |_iGy/s Max beam width Unlimited Dose Length 1.8 nGycm - 22 kGycm CT Ion chamber and RTI Chamber Adapter3 Effective length 100 mm Air kerma rate 0.3 mGycm/s to 3 Gycm/s 2 Specification valid together with RTI CT Dose Profiler 3 Specification valid together with RTI...

INDEPENDENT X-RAY QUALITY ASSURANCE Piranha Dental Specifications Resolution Bandwidth Effective Time Min dose rate 0.1 |_iGy/s Dose Rate 0.015 |_iGy/s - 320 mGy/s ±5% Trigg level 0.33 |_iGy/s Min dose rate 0.1 |_iGy/s Min dose rate 0.1 |_iGy/s Min peak dose rate 1 |_iGy/s Min pulse width 0.5 ms at 1.8 |_iGy/s Pulse Rate 0.5 - 180 ±0.5 pulses/s Min peak dose rate 1 |_iGy/s Min pulse width 0.5 ms at 1.8 |_iGy/s Pulse Rate 0.5 - 100 ±0.5 pulses/s Resolution 0.5 ms at 2 kHz sampling rate Bandwidth Dose Rate <1 kHz Pulse Rate 0.5 - 100 ±0.5 pulses/s

INDEPENDENT X-RAY QUALITY ASSURANCE RTI Light Probe Specifications RTI CT Ion Chamber 10 & 30 cm Type L100B Spectral Responce CIE V(A) (Photopic) Connector type LEMO triaxial Active volume Effective length Typical leakage Radiation quality Energy dependence Information within brackets ( ) are valid for the 30 cm chamber. with RTI Chamber Adapter Air kerma rate 0.3 mGycm/s to 3 Gycm/s RTI Group North America 33 Jacksonville Road, Bldg. 1 Towaco, NJ 07082, USA Phone: +1 800-222-7537 [email protected] www.rtigroup.com
