Procheck Smart

1 / 1 PageView full catalog

Procheck Smart

Product catalog summary

Specifications Overview:

Glucose Measurement: Requires a sample size of 0.8 µL with a reaction time of 5 seconds. The measurement range is 10 ~ 700 mg/dL (0.56 ~ 38.89 mmol/L) with a hematocrit range of 0 ~ 70%. Precision is maintained with an SD < 5 mg/dL at < 100 mg/dL and CV < 5% at ≥100 mg/dL. Packaged in a vial pack containing 50 pieces with dimensions of 43 x 40 x 58 mm.
Ketone Measurement: Requires a sample size of 1.0 µL with a reaction time of 10 seconds. The measurement range is 0.1 ~ 8.0 mmol/L with a hematocrit range of 10 ~ 70%. Precision is ≤ 1 mmol/L, SD < 0.1 mM; > 1 mmol/L, CV < 7.5%. Packaged in a single foil pack containing 50 pieces with dimensions of 96 x 10 x 220 mm.
Cholesterol Measurement: Requires a sample size of 3.0 µL with a reaction time of ≤ 60 seconds. The measurement range is 100 ~ 400 mg/dL (2.6 ~ 10.4 mmol/L) with a hematocrit range of 20 ~ 60%. Precision is CV < 7.5%. Packaged in a single foil pack containing 10 pieces with dimensions of 96 x 5.5 x 220 mm.

Device Specifications:

Procheck Smart: Dimensions are 51 x 24 x 8.8 mm with a weight of 9 g. Operating conditions range from +10ºC to +40ºC, and storage conditions range from -20ºC to +60ºC.
Compatibility: Compatible with iOS devices such as iPad Air, iPad mini 3, iPad (6th generation), iPod touch (6th generation), and various iPhone models. Requires iOS 14.0 or later.
App and Connectivity: The ProCheck app is battery-free and pocket-sized, connecting directly to smartphones via a lightning connector.

Shipping Information:

Units per carton vary with gross weights and carton sizes specified for different product configurations.

Catalog excerpts

Shipping INFO Units per Carton Gross Weight per Carton Carton Size Part No. Communication Dimension Weight Operating Condition Storage Condition 1. iPad Air, iPad mini 3 2. iPad (6th generation), iPod touch (6th generation) 3. iPhone 5s / 6 / 6s Plus / 7 Plus / XR / XS / 11 / 12 Pro Max Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other countries and regions. App Store is a service mark of Apple Inc. Copyright TaiDoc Technology Corporation. All rights reserved. 0.8 µL 5 seconds 10 ~ 700 mg/dL (0.56 ~ 38.89 mmol/L) 0 ~ 70 % SD < 5 mg/dL (0.278 mmol/L) at < 100 mg/dL (5.55 mmol/L); CV < 5% at ≥100 mg/dL (5.55 mmol/L) Vial Pack (50 pcs x 1 vial) 43 (L) x 40 (W) x 58 (H) mm Shipping INFO Units per Carton Gross Weight per Carton Carton Size Sample Size Reaction Time Measurement Range Hematocrit Range Precision Package Package Dimension 1.0 µL 10 seconds 0.1 ~ 8.0 mmol/L 10 ~ 70 % ≤ 1 mmol/L, SD < 0.1 mM; > 1 mmol/L, CV<7.5% Single Foil Pack (50 pcs) 96 (L) x 10 (W) x 220 (H) mm Shipping INFO Units per Carton Gross Weight per Carton Carton Size The power comes from the Smartphone Battery Free (Requires operating system 14.0 or later) *Some ios phones might not be compatible ProCheck app for personal health management Sample Size Reaction Time Measurement Range Hematocrit Range Precision Package Package Dimension No need for a bulky case Use only with Procheck Witty Blood Glucose / β-Ketone / Total Cholesterol Test Strips SPECIFICATIONS / STRIP Connects directly to your Smartphone Smartphone Dongle Sample Size Reaction Time Measurement Range Hematocrit Range Precision Package Package Dimension 3.0 µL ≤ 60 seconds 100 ~ 400 mg/dL (2.6 ~ 10.4 mmol/L) 20 ~ 60% CV < 7.5% Single Foil Pack (10 pcs) 96 (L) x 5.5 (W) x 220 (H) mm Shipping INFO Units per Carton Gross Weight per Carton Carton Size
