TD-3261

Product catalog summary

Overview: The document describes the 4G Cellular Blood Pressure and Blood Glucose Monitor, model TD-3261, designed for telemedicine applications. It highlights the device's ability to provide immediate telemedicine services by uploading patient data to a TeleHealth system via a 4G LTE module.

Specifications:

4G Module: Part No. ELS61-US, supports frequency bands 700 MHz (Bd12), 850 MHz (Bd5), AWS (Bd4), and 1900 MHz (Bd2).
Power Source: Rechargeable Li-Ion Battery and External DC 6V.
Memory Capacity: Stores up to 864 records.
Communication: Utilizes 4G (TD-3261G) for data transmission.
Operating Conditions: 10°C to 40°C.

Blood Glucose Monitor Features:

Uses no-coding test strips with GOD enzyme.
Sample size of 0.5 μL with a reaction time of 5 seconds.
Measurement range from 20 to 600 mg/dL.
Precision: SD < 5 mg/dL at < 100 mg/dL; CV < 5% at 100 mg/dL.
Accuracy: ±15 mg/dL if ≤ 100 mg/dL; ±15% if > 100 mg/dL.
Includes a ketone warning feature.

Blood Pressure Monitor Features:

Accuracy of pressure: ±3 mmHg or ±2% of reading.
Accuracy of heart rate: ±4% of reading.
Measurement range: Systolic 60-250 mmHg, Diastolic 30-180 mmHg, Pulse rate 40-199/minute.

Accessories:

Part No. CF3312 and CF3314 for medium and wide-range cuffs, respectively.
Arm circumference: 24-35 cm for medium, 24-43 cm for wide range.

Shipping Information:

Units per carton: 12.
Gross weight per carton: 12 kg.
Carton size: 43.3 cm (L) x 37.8 cm (W) x 36.5 cm (H).

Catalog excerpts

4G Cellular Blood Pressure and Blood Glucose Monitor Office Vacation Uploading test data to the TeleHealth system whenever you are Use SIM card to connect the mobile network (4G) Specification Frequency bands: 700 MHz (Bd12) / 850 MHz (Bd5) / AWS (Bd4) / 1900 MHz (Bd2) TaiDoc Technology Corp. Description LTE 4G Module for American Requirement Provide the immediate telemedicine for patient TeleHealth System Acquired the latest status of patient Data analysis Telemedicine without time diﬀerence! Copyright TaiDoc Technology Corporation. All rights reserved.

Open the catalog to page 1

Blood Pressure monitor Blood Glucose monitor Clever inflation technology No-coding blood glucose test strip Irregular Heartbeat (IHB) detection Smart Auto-Cycling Function Rechargeable Li-Ion Battery and External DC 6V Maximum 864 memory records 4G (TD-3261G) 180 seconds 147mm (L) x 105mm (W) x 80mm (H), 500g (include battery) 10°C ~ 40°C Power Source Memory Capacity Communication Power Saving Size of Monitor w/o Cuff Operating Condition Strip ejection Automated Averaging Function Pre-meal (AC) and Post-meal (PC) records Accuracy Ketone Warning GOD 0.5 μL / 5 seconds 20 ~ 600 mg/dL (1.1 ~ 33.3...

Open the catalog to page 2
