The TC-Log 8 USB T is a temperature data logging device capable of connecting up to 8 T type thermocouples, resistant to temperatures up to 130°C. It operates within a range of -60°C to 130°C and features a user-replaceable battery. The device connects directly to a PC via USB, eliminating the need for additional communication devices. Thermocouples are not included.

• High temperature resistance
• Quick response time
• USB direct connection to PC
• Compact size
• Real-time monitoring when connected to a PC
• User calibrable

• Easy to use
• Compatible with user-provided thermocouples
• Real-time data logging

• TC-Log 8 USB T
• Thermocouples
• TC-Log software

• Dimensions: 132 h X 80 X 25 mm
• Weight: 190 g
• Temperature range: -60°C to +130°C
• Materials: Alumide, ABS
• Number of channels: 8
• Mounted connectors: T type
• Temperature resolution: 0.1 °C
• Temperature accuracy: ± 0.2 °C with Accredia traceable certificate (calibration at -40/25/125°C and room temperature)
• Stability time: 20 minutes after a 50°C shock
• Memory capacity: 104,855 acquisitions with 1 channel, 16,383 with all 8 channels
• Acquisition step: From 1 second upwards
• Battery life: +4,320,000 acquisitions at 1 second step continuously at 25°C; infinite when connected to USB
• Battery type: AA 3.6V lithium 2Ah

The device is compatible with the TC-Log software and mobile app for enhanced data management and analysis.
