TRUE PHANTOM SOLUTIONS User ManualAdult Full Body for X-Ray CT, US [FB-A03] VERSION 2.6 ■ 25 Sept. 2026 [email protected] ■ www.truephantom.com

TRUE PHANTOM SOLUTIONS INC.

TRUE PHANTOM SOLUTIONS INC. Unpacking the phantom The phantom comes secured in a custom wooden crate and arrives almost fully assembled, with the legs and arms already attached to the torso. For packing purposes, the head comes separately and should be attached once the phantom is removed from the crate. The phantom is wrapped in a large, durable plastic sheet that should be used to lift the phantom out of the crate. Please ensure that two people perform the lift - one person holding the wrap from the shoulder side and the other from the leg side.

TRUE PHANTOM SOLUTIONS INC. Description This Adult Full Body Phantom is an X-Ray/CT and US-compatible training product. The primary application of this phantom is to train and demonstrate various patient positioning techniques in radiology. Other uses include hands-on experience with diagnostic imaging techniques and visual evaluation to find optimal scanning conditions. The model of this phantom is based on an adult male body that weighs about 70 kg (154 lb) and measures 175 cm (69 in) in height. The bones have a realistic three-layered structure with inner porosity, which can be adjusted according...

TRUE PHANTOM SOLUTIONS INC. FB-A03 | User Manual The phantom comes almost fully assembled with the legs and limbs already being fully attached to the torso. For packing purposes, the head comes detached and it requires assembly prior to using the phantom. This can be done by positioning the head in the neck brackets and using four plastic screws that come together with the phantom. Anatomy Full Human Body (10 Parts) Realistic Body Tissue-Mimicking Material Rotatable Shoulders (360° Around and 180° Sideways) Movable Hip, Knee, and ElbowJoints Detachable Head, Torso, and Limbs Adult Head - Brain...

TRUE PHANTOM SOLUTIONS INC. Front View Lateral View Perspective View

TRUE PHANTOM SOLUTIONS INC. FB-A03 | User Manual Attenuation Measured at 2.25 MHz [dB/cm] Speckles (liver, kidneys, etc.)

TRUE PHANTOM SOLUTIONS INC. FB-A03 | User Manual Conductivity Heat Capacity Diffusivity Thermal Resistivity Specific Heat Speed of Sound HU Values of the Tissue Mimicking Materials Tissue Type Body Tissue Brain Tissue Trabecular Bone Cortical Bone Vena Cava 80 (Tissue Part), -1000 (Air Filled Part)

TRUE PHANTOM SOLUTIONS INC. Rectum Wall Sigmoid Colon Wall Large and Small Intestines 80 (Tissue Part), -1000 (Air Filled Part)

TRUE PHANTOM SOLUTIONS INC. Materials Used Soft tissue and organs: Composition of urethane-based soft resin Synthetic bones: Patented ceramic-reinforced epoxy-based composite material Size and Weight of the Phantom Phantom Size: 69 Inches, Weight: 123 Lbs (approx.). Shipment Size: 46 x 36 x 17 Inches, Weight: 97 Lbs (approx.) Total Shipment Weight: 220 Lbs Included In Order Adult Full Body Phantom User Manual/Assembly Instructions 2-Year Warranty & Unlimited Customer Service Hard Carry Case Handle with Care: When lifting, carrying, or moving the phantom, use caution to avoid damage. Two-Person...

TRUE PHANTOM SOLUTIONS INC. FB-A03 | User Manual Storage and Handling The phantom is fabricated based on the anatomy of the real human body. It can be scanned per the standard protocols used while positioning a real person. The phantom can be put on horizontal and vertical positions for scanning purposes. Anterior, Lateral, and Posterior techniques can also be performed. • The phantom is made of urethane-based material and should be protected from direct exposure to any intense UV light. • The experiments conducted on the phantom can be performed in a sunny lab, but leaving the phantom under...

TRUE PHANTOM SOLUTIONS INC. FB-A03 | User Manual • The phantom is water-resistant and can be cleaned after use. It is ideal for cleaning it either with water or with soapy water. It is also quite resistant to chemicals, but if stronger solvents are meant to be used with the phantom, we recommend doing a small test on the bottom part of the neck or legs. The phantom should be placed on its belly, and the chosen solvent can be applied on a small, selected surface of the phantom for a few hours. If there is no visible effect on the phantom's surface, it is safe to assume that the phantom is resistant...
