TRUE PHANTOMSOLUTIONS Adult Female Torso (Dynamic) for X-Ray CT, US SKU: TO-A07 LUNG PUMP Right Vein] |l_eft Artery Left Vein User ManualAdult Female Torso (Dynamic) for X-Ray CT, MRI [TO-A07] VERSION 2.2 ■ 6 August 2026 [email protected] ■ http://www.truephantom.com

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual

TRUE PHANTOM SOLUTIONS INC. 1. Description The Adult Female Torso Phantom is a groundbreaking innovation in medical imaging simulation, offering an unprecedented level of anatomical accuracy. With the help of AI (Artificial Intelligence) software, this phantoms design has been directly extracted from CT scans of a live, healthy 35-year-old patient with a height of 168cm (5’5″) and a BMI adjusted to 22. As a result, it features highly realistic anatomical structures and organ positioning. Developed in collaboration with medical professionals in the United States and Switzerland, this advanced...

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual Complete Spine Complete Ribcage Shoulders and Clavicles Pelvis Partial Femoral Bones Trachea Realistic Heart with: - 2 Atria, 2 Ventricles -Appendage Feature - Flexible Valvular Structures -SVC - Esophagus Lungs Diaphragm - Body Tissue Mimicking Material - Mammary Gland Tissues Liver Large and Small Intestines Vaginal Canal ^ Beating heart model with the cyclic motion of the heart walls Water-fillable chambers with minimal air pockets Access to intravenous catheter insertion 0-240 BPM (Pulsatility) Variable Pulse Length (0-500ms) Arterial Pressure...

TRUE PHANTOM SOLUTIONS INC. Front View Side View View Back View Perspective View

TRUE PHANTOM SOLUTIONS INC. 6. Components Included Adult Torso Secondary Tubes for connecting the primary tubing to the Heart/Water Tank Lung Pump and accessories (Details in the Lung Pump Manual) Heart Pump and accessories (Details in the Heart Pump Manual)

TRUE PHANTOM SOLUTIONS INC. 7. Using a Heart Pump with the Phantom 7.1 Connecting the Heart Pump   Lay the secondary tubes on either side of the phantom. The tubing has been cut to specific length so that it dictates the arrangement of the tubing and connectors. If you have a custom order with the optional coronary arteries, the necessary branching/valving for the tubing has already been implemented. Secondary Tubes for phantom without Coronary Arteries Secondary Tubes for phantom with Coronary Arteries Attach the secondary tubes to the Phantom using the quick connect tabs provided. Attach...

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual The overall setup of the Phantom’s connection with the Heart Pump and Reservoir should be as shown below. 7.2 Disconnecting the Heart Pump and Storing the Phantom ■ To disconnect the tubes from the phantom, gently press the quick connect adapters and pull the extension tube out. ■ Tilt the phantom to allow the water to flow out. ■ Make sure the phantom is dry before storing it. Storing water in the phantom for long periods of time (over 2 weeks) can result in discoloration.

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual ■ Lay the extension tube near the top of the phantom. ■ Attach the tube to the phantom using the quick connect tab provided (The trachea opening). Lung pump _ connection point ■ Please refer to the Lung Pump's Manual for Details about how to connect the extension tubing to the pump and how to operate the pump. ■ This single outlet will be used to simulate the "inhaling" and "exhaling" motions of the lungs inside.

TRUE PHANTOM SOLUTIONS INC. The overall setup of the Phantom’s connection with the Lung Pump should be as shown below 8.2 Disconnecting the Pump and Storing the Phantom  To disconnect the tubes from the phantom, gently press the quick connect adapters and pull the extension tube out. Do not pull on the blue tubes as that could damage the phantom.

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual The complete assembled phantom should have the following configuration HEART PUMP AND RESERVOIR 11 | Page

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual ■ The phantom is fabricated based on the anatomy of a real human, and it can be scanned in supine, prone, and lateral positions; more importantly, scanning can be performed from multiple directions. ■ For ultrasound applications, this phantom can be scanned either with or without the ultrasonic gel. To get clearer images, we recommend applying a little gel to the area before scanning. You can simply wipe off the excess with a soft cloth or tissue once done. ■ You can scan the phantom while the pumps are running to get imaging results of the breathing...

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual Type of Tissue Sound Attenuation Measured at 2.25 MHz [dB/cm] Hardness [Shore OO] Organs without Speckles

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual 12.1 Thermal Properties of Bone-Mimicking Tissue Thermal Volumetric Specific Thermal Conductivity Heat Capacity Diffusivity Specific Heat 12.2 HU Values of the Tissue Mimicking Materials S.No. Tissue Type HU Value (average) Vena Cava 80 (Tissue Part), -1000 (Air Filled Part)

TRUE PHANTOM SOLUTIONS INC. Mammary Gland Tissues Vaginal Canal Rectum Wall Sigmoid Colon Wall Large and Small Intestines 80 (Tissue Part), -1000 (Air Filled Part)

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual Soft tissue and organs: Composition of urethane-based soft resin Synthetic bones: Patented ceramic-reinforced epoxy-based composite material 14. Size and Weight of the Phantom Phantom Size: 74 x 35 x 28 cm (29 x 14 x 11 Inches), Weight: 36 kg (80 lbs) (approx.) Lung Pump Size: Size: 36 x 12 x 8 Inches, Weight: 48 Lbs (approx.) Heart Pump Size: Size: 27.5 x 8 x 10 Inches, Weight: 39 Lbs (approx.) Shipment Size with Hard Carry Case: 46 x 36 x 17 Inches, Weight: 136 Lbs (approx.) Size of Lung Pump Package: 49 x 17 x 13 Inches, Weight: 62.5 Lbs (approx.)...

TRUE PHANTOM SOLUTIONS INC. TO-A07 | User Manual 17.Storage • The phantom is fabricated from the CT scans of a real human body. It can be scanned per the standard protocols used while positioning a real person. • The phantom can be put on horizontal and vertical positions for scanning purposes. • Anterior, Lateral, and Posterior techniques can also be performed. • When moving the phantom to another location, use a stretcher or wheeled table instead of carrying it. • The experiments conducted on the phantom can be performed in a sunny lab, but leaving the phantom under direct sunlight for weeks...
