OPTICA™ 40

OPTICA™ 40
1 / 2Pages

Catalog excerpts

OVERVIEW The Optica™ 40 is a motorized collimator for integration with radiography and fluoroscopy systems. The collimator is controlled with the front knobs or remotely through its CAN-bus. A large touch-screen LCD display shows the X-ray tube tilting angle, selected beam filtration and field size with a given SID. The Optica 40 is equipped with a long-life power LED that projects a bright light field on the exposed area. Aligning the detector under the X-ray beam is made easy with a center laser line. The beam filtration is possible with the optional motorized filter module. No filtration or three different aluminum plus copper combination filtrations are available. Shutter calibration and customization of user settings are easily performed through the software menu, accessible via the display. APPLICATIONS • Stationary X-ray equipment for radiography and fluoroscopy up to 150 kV tube voltage.

Open the catalog to page 1

Technical Specifications Collimation Rectangular field Attenuation equivalent 1.2 mm Al.eq at 75 kVp (IEC 60601-1-3:2008) Additional Filters 2 additional motor driven filters; manually (IEC 60601-1-3:2008 §7.3 / §74) selectable or by CAN-bus. Selectable filter combinations: • No added filter • Filter 1 =1 mm Al + 0.1 mm Cu • Filter 2 =1 mm Al + 0.2 mm Cu • Combined: 2 mm Al + 0.3 mm Cu Bucky center line laser Class 1 laser (IEC 60825-1) Light field illuminance >230 lx with LED power set to 100% Leakage radiation <0.5 mGy/hr Accessory rails For two (2) accessory slides of Compliance Conforms...

Open the catalog to page 2
