WeberBrain® Laser Infrared Helmet

Product catalog summary

Product Overview: WeberBrain® is a non-invasive technology designed to support cognitive and mental health through the use of red and infrared laser light. It features 38 HEX-shaped panels that provide full cortical coverage across the human cerebral cortex, including frontal, temporal, parietal, and occipital regions.

Specifications: Each HEX panel contains 6 high-precision laser diodes, with two diodes for each wavelength: 650nm, 808nm, and 1064nm, totaling 228 diodes. The Pro version includes 684 diodes, integrating all three wavelengths into one compact diode package for enhanced performance.

Design and Functionality: The device is designed to target deep brain tissue with conically-shaped ends, known as light fingers, that direct laser light onto the scalp. A lens system focuses the laser light into a fine beam under 1mm in diameter for maximum penetration.

Customization and Control: The WeberBrain® App allows users to adjust frequency and power output, creating personalized sessions. The SmartLink connects the device to the app or functions as a standalone controller. The Pro version offers targeted brain region stimulation and customizable presets.

Hygiene and Maintenance: The CleaningPod, available as an optional accessory, uses UV-C disinfection to maintain hygiene and consistent performance. The device features durable housing for safe and reliable operation.

Additional Information: For more details, visit the official website at www.webermedical.com.

Catalog excerpts

Memory. Focus. Performance.

Open the catalog to page 1

Clearer thinking Smart support for your brain. With WeberBrain® you can support cognitive and mental health — powered by a safe, non-invasive technology.

Open the catalog to page 2

38 individual HEX-shaped panels deliver red and infrared laser light to the brain. Full cortical coverage. Diodes are precisely aligned across all four regions of the human cerebral cortex. Frontal Temporal right Temporal left

Open the catalog to page 3

Triple-wavelength performance. Each HEX panel holds 6 high-precision laser diodes. 2 for every wavelength: 650nm, 808nm and 1064nm. A total of 228 diodes ensures intuitive operation and perfect calibration. Power-packed precision. Each HEX panel hosts 6 diode packages. All three wavelengths are integrated into one compact diode package. That makes 684 diodes for a customized and powerful laser experience without limits.

Open the catalog to page 4

Ultra effective Designed to target deep brain tissue. The conically-shaped ends – or light fingers as we call them – direct laser light straight onto the scalp without being blocked by hair. Three different wavelengths in the red and infrared range guarantee optimum tissue stimulation and regeneration. Increasing penetration dept

Open the catalog to page 5

Precision and focus. Achieved by a lens system that concentrates laser light into a fine beam under 1mm in diameter – for maximum optical output power and deep penetration. Perfect fit. Adjustable sliders ensure a comfortable fit for any head shape and size. Front slider Back slider

Open the catalog to page 6

With the WeberBrain® App, you can adjust frequency, power output, and more — creating sessions that fit your needs. Save Parietal settings Output power Output power Frequency Output power The SmartLink connects the WeberBrain® to the app or works as a standalone controller. Google Play

Open the catalog to page 7

The Pro version. Lets you target specific brain regions for unmatched precision. Customize your own presets and use them anytime. Clean by design. UV-C disinfection keeps the WeberBrain® hygienic and maintains consistent performance. Durable housing. Safe and reliable operation. Tips: Long press region to duplicate settings

Open the catalog to page 8

Learn more on: www.webermedical.com Weber Medical GmbH | Sohnreystr. 4 | 37697 Lauenförde | Germany | [email protected]
